  • Page 1 HMD908/HMD908AUS PORTABLE MAGNETIC DRILLS OPERATOR’S MANUAL ® FOR USE WITH “12,000-SERIES” HOUGEN CUTTERS...

  • Page 2: Safety First

    No other expressed warranty is given or authorized. Hougen Manufacturing, Inc. disclaims any implied warranty of MERCHANTABILITY or FITNESS for any period beyond the expressed warranty and shall not be liable for incidental or consequential damages.
  • Page 3 8. Your Magnetic Drill was factory adjusted prior to Complete and mail the Product Registration Card now. shipping. Check to make sure that all gib It is important that Hougen Manufacturing, Inc. have a adjustment screws, motor mount screws, front record of product ownership.
  • Page 4 Arbor and cutter should never be used as a hand hold. Keep hands and clothing away from all moving parts. Do not use Hougen Cutters where ejected slug might cause injury (slug ejected at end of cut). Be sure that all safety devices are properly adjusted and in use. Also, adhere to all operating instructions. Do not drill through any surface that may contain live electrical wiring.
  • Page 5 TABLE 1 TABLE 2 Metal Screw Cover of Grounded Outlet Box Adapter Grounding Means...

  • Page 6: Operating Instructions

    6. Make certain that cutter is clear of workpiece and turn motor ON by pressing the motor START button. 7. Feed Hougen Cutter slowly into workpiece. Only after cutting path is established to a depth of about 1/16" can full force be applied to feed handles.
  • Page 7 4. Insert proper pilot in shank end of Hougen Cutter. 5. Insert Hougen Cutter until flat on cutter shank is aligned with set screw holes and is exactly perpendicular to axis of set screw holes. If 1/2" diameter shank cutter is used, slip (10851) Arbor Adapter over the cutter shank with adapter hole positioned exactly over flat on cutter shank prior to inserting into Arbor bore.
  • Page 9 MOTOR PARTS LISTING l l a l l a l l a l l a l e i ) t r...
  • Page 10 CONTROL PANEL HOOK UP DIAGRAM Power Cord (White 22 ga.) Power Cord (Black 22 ga.) Motor Cord (White18 ga.) Motor Cord (Black 18 ga.) J6 J5 Safety Switch (Black 16 ga.) Safety Switch Magnet Wires (White 16 ga.) (Yellow 22 ga.)

  • Page 11: Control Panel Parts List

    CONTROL PANEL PARTS LIST 02409 01334 01335 01226 01228 04671 02548 02568 02550 04041 04498 (Aus Only) 10977 02547...

  • Page 13: Drill Parts List

    DRILL PARTS LIST " 4 " 1 " 8...

  • Page 14: Maintenance

    5. Remove arbor and pack the bearing in the front support bracket with grease. Use Shell Cyprina-RA or equivalent. HINTS FOR SMOOTHER OPERATION 1. Keep insides of Hougen Cutter clear of chips. Chips will interfere with cutting to maximum depth, may impede the free oil flow and can cause cutter breakage.
  • Page 15 HMD908 “12,000-SERIES” ACCESSORIES " 1 " 2 & > > > " 2 > > t s i l l i r t s i l l i r t s i s l l " 1 " 2 " 2 >...
  • Page 16 1611 Boylston Seattle, WA 98122 (206) 322-2726 Hougen Manufacturing, Inc. P.O. Box 2005 • Flint, MI 48501-2005 3001 Hougen Drive • Swartz Creek, MI 48473 Phone (810) 635-7111 • FAX (810) 635-8277 E-mail: www.hougen.com OM9080204 Online: info@hougen.com © 2004 Hougen Manufacturing, Inc.
