Eliwell ICPlus 902 Manual page 20

PAR. DESCRIPTION
CONFIGURATION (folder 'CnF')
Probe type selection.
• NTC/PTC: Ptc (0) = PTC, ntC (1) = NTC
H00 • PT100-Tc: Jtc (0) = TcJ, Htc (1) = Tck, Pt1 (2) = PT100.
• V/I: 420 (0) = 4...20mA, 020 (1) = 0...20mA, t10 (2) = 0...10V,
t05 (3) = 0...5V, t01 (4) = 0...1V.
Press the ESC, UP and DOWN keys (if configured for a second function) for the
H02 time H02 to activate the function itself.
N.B.: The AUX function has a fixed activation time of 1 second.
Lower input current/voltage limit.
H03
(only present on model V/I)
Upper current/voltage limit for input.
H04
(only present on model V/I)
Window filter:
H05
-2 = very fast; -1 = fast; 0 = normal; 1 = slow; 2 = very slow.
Key or Digital Input with aux/light or door switch active with the device OFF (but
H06
powered). n (0) = not active; y (1) = active.
Stand-by operating mode.
H08 0 = only display switches off; 1 = display on and controllers locked;
2 = display off and controllers locked.
Delay for output activation after Power On. If H10 = 0 the delay is NOT active; if
H10
H10 ≠ 0 the output will not be activated before this time has expired.
Configuration of UP key.
H31 0 = disabled; 1 = SOFT START; 2 = Offset setpoint; 3 = Outputs stopped;
4 = Periodic cycle; 5 = AUX output; 6 = Stand-by; 7 = not used.
H32 Configuration of DOWN key. Same as H31.
If one or more parameters are changed, the controller MUST be switched off and switched on again.
MODEL RANGE VALUE M.U. LEVEL
NTC/PTC Ptc/ntC
PT100-Tc Jtc/Htc/Pt1
420/020
V/I
t10/t05/t01
ALL 0...15
NTC/PTC
PT100-Tc
V/I -1999...1999
NTC/PTC
PT100-Tc
V/I -1999...1999
ALL -2/-1/0/1/2
ALL n/y
ALL 0/1/2
ALL 0...250
ALL 0...7
ALL 0...7
ntc flag
Jtc num
User/Inst
420 num
5 secs Inst
User/Inst
0 num
User/Inst
1000 num
0 num Inst
y flag Inst
2 num Inst
0 min Inst
0 num Inst
0 num Inst
