Using The Copy Card - Eliwell ICPlus 902 Manual

Electronic controller with 1 intervention point

Table of Contents

The Copy Card is connected to the serial port (TTL) and allows rapid programming of the instrument parameters. Access Installer parameters by

entering 'PA2' , scroll through the folders using

and

, then select the function using

• Upload (UL):

Select UL and press

procedure is a success, 'y' , will appear on the display, otherwise 'n' will appear.

• Format (Fr):

This command is used to format the copy card (recommended when using the card for the first time).

Important: the Fr parameter deletes all data present. This operation cannot be cancelled.

• Download:

Connect the Copy Card when the instrument is switched off. At power-on, data is downloaded from the copy card to the

instrument automatically. At the end of the lamp test, the display will show 'dLy' if the operation was successful and 'dLn'

if not.

NOTE:

After downloading, the instrument works with the settings of the new map just downloaded.

USING THE COPY CARD

and

(eg. UL).

. This function uploads the programming parameters from the instrument to the card. If the

UPLOAD

until folder FPr appears. Select it using

DOWNLOAD

, scroll through the parameters using
