9. MECHANICAL AND ELECTRICAL DRAWINGS

This section contains mechanical and electrical drawings for the TriStar II 3020. These draw-
ings show assemblies in great detail. Some parts listed in these prints may be available only as
an assembly or in a kit. Do not provide copies of these drawings to a customer.

Mechanical

Refer to the following table for a list of the mechanical prints. Double-click on the part number
to view the print.
Print Number
302-00000-20
302-34000-00
302-34001-00
302-34002-00
302-34003-00
302-34004-00
302-34004-01

Electrical

Refer to the following table for a list of the electrical drawings. Double-click on the part num-
ber to view the print.
Print Number
302-17701-011
302-17701-511
302-17702-011
302-17702-511
302-17703-011
302-17703-511
302-17704-011
302-17704-511
302-63803-00
Jul 09
Assembly, Core Unit
Assembly, Semi-Final
Assembly, Main Chassis
Assembly, Card Cage
Assembly, Power
Assembly, Analysis Module, Nitrogen
Assembly, Analysis Module, Krypton
Backplane PCB
Backplane Schematic
Digital Interface PCB
Digital Interface Schematic
Analysis Module PCB
Analysis Module Schematic
Vacuum Pump Reset PCB
Vacuum Pump Reset Schematic
Cable, Inlet Manifold Valves
Description
Description
Mechanical
9-1
