TriStar II 3020 Service
This section contains a list of approved repair parts for this instrument. The items with an
asterisk (*) are included in the Service Parts Kit, P/N: 302-33680-00.
Part Number
003-17642-011*
003-22617-00*
003-22626-00*
003-40051-00*
003-51188-00
003-55617-01
003-55635-00*
003-60046-01
003-60805-00
003-60820-00
003-60822-00
003-63801-00
003-63811-07
003-63811-36
003-63813-26
003-63833-04
004-24001-00
004-25006-00*
004-25022-00*
004-25044-00*
004-25116-00
004-25117-00
004-25131-00*
004-25132-00*
004-25138-00*
004-25336-00
Jul 09

10. SERVICE PARTS

CPU PCB Assembly
Solenoid Valve 24 VDC, Clippard ET-2M-24
Valve, Solenoid 24VDC 10-32 MT, .060 dia. orifice (25 psig)
Power Supply, Quad
Circuit Breaker
Transducer, 10-torr
Transducer, 0-30 psia
Cable, 18 GA 3 Cond Power Belden
Cable, RTD, 1000 Ohm
Cable, LED Panel Mnt, Grn, 42 in.
Cable IEC, Pwr
Cable, Cat5, 8 Cond, RJ45, RJ45, N, 120
Cable, Ribbon, 9 Cond, DF, DF, N, 055 in.
Cable, Ribbon, 9 Cond, DF, DF, N, 036 in.
Cable, Ribbon 26 Cond, Twst Pr, N, 201
Cable, Cable, 9 Cond, UML9 UML9, NS, 571
Handle, 1.50 x .75 x 5/32 dia.
O-ring, -006 70 Duro Buna-N
O-ring, -0012 70 Duro Buna-N
O-ring, -0013 70 Duro Buna-N
Ferrule, Front, 1/2 in., Teflon
Ferrule, Front, 1/2 in., Nylon
Ferrule, Front, 1/8 in., Teflon
Ferrule, Front, 1/8 in., Nylon
Fitting, Comp, 1/8 Tube
Dowel Pin, 1/16 dia x 1/2 Lg SS
Description
Service Parts
10-1
