local fluctuations of temperature, which would reduce the precision of gas measurements.
There is a temperature sensing device (RTD) mounted to the chamber.

Sample analysis manifold

Sample Analysis Photo
The Sample Manifold contains the three sample ports and a P
the TriStar's three ports has a 20-µm frit to prevent sample from entering and clogging the
system, a small-orifice solenoid valve for dosing, a large-orifice solenoid valve for evacuation,
1000-Torr transducer, and a pressure relief valve to protect against excess pressure build up
caused by too rapid desorption. The relief valves vent at 10 to 20 psig, even if there is no
power applied to the instrument and protect the sample transducers, sample tubes and dewar.
The P port is used for continuous saturation pressure measurement.
0
Jul 09
10-Torr Transducer
(Krypton units only)
Pressure relief valve
Sample ports
Sample Analysis CAD
Interior Modules
Dosing volume
manifold
Solenoid valve
Transducer
port for the instrument. Each of
0
2-7
