9. MECHANICAL AND ELECTRICAL DRAWINGS

This section contains mechanical and electrical drawings for the Gemini analyzers. These
drawings show assemblies in great detail. Some parts listed in these prints may be available
only as an assembly or in a kit. The approved repair parts for servicing this instrument are
listed in Chapter 10, Service Parts.
Do not provide copies of these drawings to a customer.

Mechanical

Refer to the following table for a list of the mechanical prints. Double-click on the part number
to view the print.
Print Number
239-34002-00
239-34010-00
239-34000-00
239-34000-01
239-34001-00
239-34004-00
239-34004-01
239-34005-00
239-34000-02
239-34001-01
239-34004-01
239-34005-01
Feb 09
Common for all Geminis
Assembly, Electronics module
Assembly, User Interface (keypad)
Gemini VII 2390a, Gemini VII 2390p
Assembly, Semi-Final, Gemini 2390a
Assembly, Semi-Final, Gemini 2390p
Assembly, Chassis
Assembly, Analysis module, Gemini 2390a
Assembly, Analysis module, Gemini 2390p
Assembly, Elevator
Gemini VII 2390t
Assembly, Semi-Final
Assembly, Chassis
Assembly, Analysis module
Assembly, Elevator
