6.19.- BACKLIGHT, TURNING ON THE BACKLIT DISPLAY
This screen is used to programme the maximum brightness time of the display since the device
was last used with the keypad. After this time, the display will reduce the brightness level.
Press the
of the screen.
Press the
When the desired value is shown on the screen, use the
cursor.
Maximum programming value: 999 seconds.
Minimum programming value: 1 second.
To validate the value, press the
If the value entered by the user is out of the range of programming values, the programmed
value will be deleted and the system will restore it to the last saved value.
Press key
6.20.- RS-485 COMMUNICATIONS
The RS-485 communications protocol is selected on this screen.
Press the
of the screen.
54
key for 3 seconds to enter the edit mode. The prog icon will flash on the left
key to modify the value of the flashing digit.
to access the next programming step.
key for 3 seconds to enter the edit mode. The prog icon will flash on the left
key for 3 seconds; the prog icon will stop flashing.
CVM-E3-MINI
and keys to move the edit
