Related Manuals for ABB PowerValue 11 RT 6 kVA
Summary of Contents for ABB PowerValue 11 RT 6 kVA
- Page 1 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 PowerValue 11 RT 6-10 kVA User Manual © Copyright 2014 ABB, All rights reserved. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 1/37 ABB Modifications reserved...
- Page 2 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 2/37 ABB Modifications reserved...
-
Page 3: Foreword
A terminal to which or from which a direct current or voltage (DC) may be applied or supplied Battery Power On, Idle or shutdown the UPS Overload indication Recycle Do not dispose with ordinary trash 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 3/37 ABB Modifications reserved... -
Page 4: Table Of Contents
Without mains supply (Cold start) ....................24 3.3.2 UPS Shutdown ........................24 With mains supply .......................... 24 Without mains supply ........................24 3.4 Display Operation ......................24 3.4.1 Changing the operating-mode ..................... 24 3.4.2 Navigation ..........................25 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 4/37 ABB Modifications reserved... - Page 5 4.3.1 Installing a Serial Network Management Card (optional) ........... 31 4.3.2 Monitoring Software......................31 MAINTENANCE ......................32 TROUBLESHOOTING ....................33 6.1 Fault identification and rectification ................33 6.2 Accessing Alarms ......................33 TECHNICAL SPECIFICATION ................... 36 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 5/37 ABB Modifications reserved...
-
Page 6: Safety Instructions
• 2006/95/EC Low voltage directive. • 2004/108/EC Electromagnetic Compatibility directive (EMC). Standards as reference: • EN-IEC 62040-1. Uninterruptible power supply (UPS). Part 1-1: General and safety requirements for UPS’s used in accessible areas by end users. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 6/37 ABB Modifications reserved... -
Page 7: Inquiries
This UPS may be connected to a maximum of four External battery enclosures. Do not dispose batteries on fire as they may explode. Do not open or mutilate batteries. Released electrolyte is harmful to the skin and eyes. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 7/37 ABB Modifications reserved... -
Page 8: Maintenance, Servicing And Faults
When changing the batteries, replace with the same quantity and the same type of batteries. Replace the fuses only by fuses of the same type and amperage in order to avoid fire hazards. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 8/37 ABB Modifications reserved... -
Page 9: Installation
- Leave 50cm of space on each side of the cabinet to enable cooling airflow and ensure that the circulation of air to the ventilation slits is not obstructed. - Avoid excessively high temperature and excessive moisture. - Make sure that the surface is solid and flat. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 9/37 ABB Modifications reserved... -
Page 10: Positioning
2. Plug the External Battery Enclosure cable into the UPS battery connector as indicated in 3. Figure 3. Figure 3: Battery Module Connections 4. Position and screw the UPS and the Battery Module front panel. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 10/37 ABB Modifications reserved... - Page 11 Figure 4. Figure 4: Battery Module Connections 2.2.2.2 Standalone / Tower Installation PowerValue 11 RT 6 kVA Carefully rotate the LCD control panel of 90º to the right in the UPS and in the battery modules. Figure 5: Display rotation 2.
-
Page 12: General Characteristics
The UPS rear panel’s description table and pictures are shown below: Number Description Number Description AC output USB port AC input Parallel port Bypass RS-232 Battery connector SNMP/ AS400 slot Ground contact Output circuit breaker 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 12/37 ABB Modifications reserved... -
Page 13: Electrical Installation
Figure 9: PowerValue 11 RT 6 kVA rear view Figure 10: PowerValue 11 RT 10 kVA rear view Electrical Installation 2.4.1 Commissioning The UPS must be commissioned by a fully trained and authorized field service engineer before being put into use. -
Page 14: Connections
WARNING! 2.4.3 Connections To access the terminal blocks, remove the 2 screws from the terminal block cover. Figure 13: PowerValue 11 RT 6 kVA Terminal block Figure 14: PowerValue 11 RT 10 kVA Terminal block 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 14/37 ABB... - Page 15 Use appropriate tools and terminal splices to guarantee a reliable contact between the wires and the terminal blocks. Figure 16: Single Input Feed connections for 6kVA units Figure 17: Single Input Feed connections for 10 kVA units 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 15/37 ABB Modifications reserved...
- Page 16 3. Connect the input, output and bypass cables Use appropriate tools and terminal splices to guarantee a reliable contact between the wires and the terminal blocks. Figure 22: Dual Input Feed connections for 6kVA units 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 16/37 ABB Modifications reserved...
- Page 17 If such loads are connected to the UPS, the start-up power consumed by these devices should be considered when calculating the capacity of the UPS. If this is not taken into consideration, the UPS goes often in overload and may turn off easily depending on its dimensioning. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 17/37 ABB Modifications reserved...
-
Page 18: Initial Startup
- When the distance between the UPS in parallel and the breaker panel is more than 10 meters, the length difference between input and output cable of the UPS is required to be lower than 5%. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 18/37 ABB Modifications reserved... -
Page 19: Installing A New Parallel System
7. If the difference output voltage is lower than 0.5V, switch on the output breakers for both UPS separately and switch on the main output (O/P) breakers. 8. Transfer the mains mechanical or static switch to the UPS. The system will then run in parallel. Figure 28: Parallel System Installation Diagram 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 19/37 ABB Modifications reserved... -
Page 20: Adding An Ups To An Existing Parallel System
Adequate lighting is provided around all UPS equipment. Any optional accessories are mounted in their installed location and properly wired. Start-up and operational checks performed by authorized service personnel. All network connections are completed. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 20/37 ABB Modifications reserved... -
Page 21: Operation
Power On/Off Turn on and off the UPS or change operating-mode. Scroll up Enter/Exit the menus and scroll across the screens. Scroll down Scroll down the menu Select / Edit Select and confirm settings. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 21/37 ABB Modifications reserved... -
Page 22: Lcd Display
For detailed information on how to operate the LCD, see Section 3.4. Operating-mode Different symbols indicate the status and the operating-mode of the UPS. Such symbols appear always in the position indicated in Figure 32. Figure 32: Operating-mode 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 22/37 ABB Modifications reserved... -
Page 23: Ups Start-Up And Shutdown
2. Press the power-on button continuously for more than 1 second. The fans will be activated and the UPS will load for a few seconds. 3. The UPS will perform a self-test and the LCD will then show the default UPS status summary screen. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 23/37 ABB Modifications reserved... -
Page 24: Without Mains Supply (Cold Start)
From battery-mode to online-mode: Connect the power supply to the UPS and it will transfer automatically to online-mode. Note: If the bypass is disabled in the settings menu, when pressing the power-on button for 3s, the UPS goes from online-mode to stand-by-mode. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 24/37 ABB Modifications reserved... -
Page 25: Navigation
Reset all the events from the log file No/Yes Recover all settings in the LCD menu and the Restore factory EPO polarity and locks the DC start-up (can be No/Yes settings executed only when UPS is in bypass mode) 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 25/37 ABB Modifications reserved... - Page 26 The alarm will stop and the UPS will transfer to bypass-mode. Figure 35 gives an overview on how to navigate on the control menu. Figure 35: Control menu tree 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 26/37 ABB Modifications reserved...
- Page 27 When the frequency in the bypass is below this limit, 1%~10% limit the UPS changes running mode. Bypass frequency high When the frequency in the bypass is above this limit, 1%~10% limit the UPS changes running mode. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 27/37 ABB Modifications reserved...
- Page 28 Table 1: Settings menu information **Read Section 3.2, before using ECO-mode (HE mode) or converter function. ***Ensure the real battery quantity is same as the settings not to damage the batteries. Figure 37: Setting menu tree 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 28/37 ABB Modifications reserved...
- Page 29 Example: Setting the rated output voltage value (Figure 38). Note: The UPS must be in bypass to change this parameter. Figure 38: Setting rated output voltage value 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 29/37 ABB Modifications reserved...
-
Page 30: Communication
To establish communication between the UPS and a computer, connect the USB cable that comes with the UPS to the USB port on the UPS. Connect the other end of the USB cable to the USB port on a computer. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 30/37 ABB Modifications reserved... -
Page 31: Network Management Card (Optional)
Monitoring Software ABB UPS can be monitored through a software that allows the user to monitor the UPS. The software provides a remote and safe shutdown for multi-client systems in case of absence of power in the output of the UPS. -
Page 32: Maintenance
- Replace batteries with the same number and same type of batteries. - Do not replace the batteries individually. All the batteries should be replaced at the same time following the instructions of the battery supplier. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 32/37 ABB Modifications reserved... -
Page 33: Troubleshooting
Event Log list. 3. Scroll through the listed events, notices, and alarms using buttons or . Note: The most recent events are displayed on top of the list (eg. 1/50) 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 33/37 ABB Modifications reserved... - Page 34 Battery-mode is available and your equipment is protected. EPO Active The external contacts in the rear of the UPS Check the EPO connector status Alarm Code: 71 are configured for EPO operation and they have been activated. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 34/37 ABB Modifications reserved...
- Page 35 2. Date on which the problem occurred 3. LCD/LED display information, Buzzer alarm status 4. Mains power condition, load type and capacity, environment temperature, ventilation condition 5. Information on external battery pack (battery capacity, quantity) 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 35/37 ABB Modifications reserved...
-
Page 36: Technical Specification
SNMP, AS400 RS485 card (option) STANDARDS Safety IEC/EN 62040-1 IEC/EN 62040-2 Performance IEC/EN 62040-3 Manufacturing ISO 9001:2008, ISO 14001:2004 WEIGHT, DIMENSIONS Weight 20.1 28.1 Dimensions WxHxD 438x129x594 438x215.5x594 *Technical specifications are subject to change without notice. 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 36/37 ABB Modifications reserved... - Page 37 614-00798-00 04-3788_ABB_OPM_PVA11 6-10kVA-RT_EN_140423 Page 37/37 ABB Modifications reserved...
