UG-1042 Easy to Use AD4000 Series 16-/18-/20-Bit Precision SAR ADCs User Guide
Name Part Description
C56 10 µF, X5R, 25 V, 0805, MLCC
capacitor
C58, C65 2.2 µF, 50 V, 0805, X7R capacitors
C186 SMD capacitor
L1
1000 Ω at 100 MHz, 1206, WE-CBF
SMD, EMI suppression ferrite
L3 10 µH, inductor, shielded power,
XAL40 series
L4 2.2 µH, inductor, shielded power,
XAL40 series
LED1 LED, SMD green
R1 2.4 kΩ, 0.063 W, 1%, 0603 resistor
R2 100 kΩ, 0.1 W, 1%, 0805 resistor
R3, R11, R12, R13, R14, 0 Ω, SMD resistors
R20, R21, R23, R25,
R36, R38, R40, R42,
R44, R46, R48, R50,
R51, R52, R53, R59,
R66, R68, R69, R73,
R74, R75, R77, R78,
R79, R85, R86, R90,
R91, R95, R96, R99,
R100
R4, R5, R8, R9 1 kΩ, 0.063 W, 1%, 0603 resistors
R7 88.7 kΩ, 1%, 0805 resistor
R10 1%, 0805 resistor
R17, R22, R32, R37 49.9 Ω, 0.1 W, 0.1%, 0805 resistors
R24, R41 200 Ω, 0.1 W, 1%, 0805 resistors
R27, R28, R34, R35 Thick film chip resistors
R45, R65, R67 10 kΩ, 0.1 W, 1%, 0805 resistors
R93 20 kΩ, 0.063 W, 1%, 0603 resistor
R6, R15, R16, R18, R19, SMD resistors, 0603
R26, R29, R30, R31,
R33, R39, R43, R49,
R54, R55, R56, R57,
R58, R60, R70, R71,
R72, R76, R80, R84,
R87, R88, R89, R92,
R94, R97, R98, R101
Table 6. Evaluation Board Models
Product Ordering Model
AD4000BRMZ EVAL-AD4000FMCZ
AD4001BRMZ EVAL-AD4001FMCZ
AD4002BRMZ EVAL-AD4002FMCZ
AD4003BRMZ EVAL-AD4003FMCZ
AD4020BRMZ EVAL-AD4020FMCZ
Manufacturer
Murata
TDK
EPCOS
Wurth
Coilcraft
Coilcraft
OSRAM
Multicomp
Multicomp
Multicomp
Multicomp
Vishay Draloric
Multicomp
Panasonic
Multicomp
Vishay Draloric
Multicomp
Multicomp
Not applicable
Sample Rate (MSPS) Resolution (Bits)
2 16
2 16
2 18
2 18
1.8 20
Rev. E | Page 24 of 25
Part Number Stock Code
GRM219R61E106KA12D FEC 2426961
C2012X7R1H225K125AC FEC 2346945
B37921C9104K60 Digi-Key 495-3265-1-ND
742792141 Wurth 742792141
XAL4040-103ME XAL4040-103ME
XAL4020-222MEB Coilcraft XAL4020-222MEB
LGQ971 Digi-Key 475-1409-1-ND
MC0063W060312K4 FEC 9330879
MC01W08051100K FEC 9332405
MC 0.063W 0603 0R FEC 9331662
MC0063W060311K FEC 9330380
CRCW080588K7FKEA FEC 2139026
MC01W08050R FEC 9333681
RN73C2A49R9BTG FEC 1140694
MC01W08051200R FEC 9332758
CRCW0805590RFKEA FEC 1653021
MC01W0805110K FEC 9332391
MC0063W0603120K FEC 9330771
Not applicable Do not place
Package Used on Evaluation Board
10-lead MSOP
10-lead MSOP
10-lead MSOP
10-lead MSOP
10-lead MSOP
