Configuring The Daily Tariff Schedule - Satec PM172P Installation And Operation Manual

Chapter 4 PAS Application Software
Series PM172 Powermeters
Configuring Summary Energy and TOU Registers
The available options are shown in the following table:
Parameter Options
TOU Unchecked
Checked
Use Profl Unchecked
Checked
Dmd Profl Unchecked
Checked
Sum Profl Unchecked
Checked
Units kWh, kvarh, kVAh,
m 3 , CF (cubic foot),
CCF (hundred cubic
feet)
None
Source
kWh Import
Input
kWh Export
kvarh Import
kvarh Export
kVAh,
DI1-DI2
Multiplier 0.001 to 100.000
Target Reg#1- Reg#8

Configuring the Daily Tariff Schedule

To configure your daily tariff schedule, select Energy/TOU from the Meter
Setup menu, and then click on the TOU Daily Profiles tab.
The daily profile setup allows you to specify the daily tariff change points with
a 15-minute resolution for 4 seasons using 4 different daily schedules for
each season.
To configure your daily profiles:
1. Select the desired season and day type.
2. Select the start time for each tariff change point and the corresponding
active tariff number.
3. Repeat the setup for all active profiles.
The first tariff change point is fixed at 00:00 hours, and the last tariff change
you specified will be in use until 00:00 hours on the next day.
The energy daily profile log will be automatically configured for the number of
active tariffs you defined in the meter TOU daily profile.
Default
Summary/TOU Registers
Unchecked Links tariff registers to the selected
energy source
Unchecked Enables automatic daily profiling for
energy usage registers (both total and
tariff registers if TOU is enabled)
Unchecked Enables automatic daily profiling for
maximum demand registers (both total
and tariff registers if TOU is enabled)
Unchecked Enables daily profiling for summary
registers (total of all tariffs)
None The register measurement units. When
a register is linked to an internal energy
source, it is set automatically. When an
external pulse source is used, the user
can select a measurement unit for the
register.
Register Source List
None Links an energy source to the register
1.000 The multiplication factor for the energy
source.
None Defines the target billing register for the
energy source. It is set automatically.
