Appendix B Analog Output Parameters

Appendix B
nonE
rt.U1
rt.U2
rt.U3
rt.U12
rt.U23
rt.U31
rt.C1
rt.C2
rt.C3
rt.Ac.P
rt.rE.P
rt.AP.P
rt.PF
rt.PF.LG
rt.PF.Ld
rt.nEU.C
rt.FrEq
Ar.U1
Ar.U2
Ar.U3
Ar.U12
Ar.U23
Ar.U31
Ar.C1
Ar.C2
Ar.C3
Ar.Ac.P
Ar.rE.P
Ar.AP.P
Ar.PF
Ar.PF.LG
Ar.PF.Ld
rt.nEU.C
rt.FrEq
d.P.i
d.P.E
d.q.i
d.q.E
d.S
122
Analog Output Parameters
The following table lists parameters that can be provided on the meter's
analog outputs and on the external analog expander outputs.
Display Code Designation
NONE
1
V1/12 RT
1
V2/23 RT
V3/31 RT 1
V12 RT
V23 RT
V31 RT
I1 RT
I2 RT
I3 RT
kW RT
kvar RT
kVA RT
PF RT
PF LAG RT
PF LEAD RT
In RT
FREQ RT
V1/12 AVR
V2/23 AVR
V3/31 AVR
V12 AVR
V23 AVR
V31 AVR
I1 AVR
I2 AVR
I3 AVR
kW AVR
kvar AVR
kVA AVR
PF AVR
PF LAG AVR
PF LEAD AVR
In AVR
FREQ AVR
kW IMP ACC DMD
kW EXP ACC DMD
kvar IMP ACC DMD
kvar EXP ACC DMD
kVA ACC DMD
1
In 4LN3, 3LN3 and 3BLN3 wiring modes, the voltages will be line-to-neutral; for
any other wiring mode, they will be line-to-line voltages.
None (output disabled)
1-Cycle Phase Values
V1/V12 Voltage
V2/V23 Voltage
V3/V31 Voltage
V12 Voltage
V23 Voltage
V31 Voltage
I1 Current
I2 Current
I3 Current
1-Cycle Total Values
Total kW
Total kvar
Total kVA
Total PF
Total PF Lag
Total PF Lead
1-Cycle Auxiliary Values
In Current
Frequency
1-Sec Phase Values
1 V1/V12 Voltage
1 V2/V23 Voltage
1 V3/V31 Voltage
V12 Voltage
V23 Voltage
V31 Voltage
I1 Current
I2 Current
I3 Current
1-Sec Total Values
Total kW
Total kvar
Total kVA
Total PF
Total PF Lag
Total PF Lead
1-Sec Auxiliary Values
In Current
Frequency
Present Demands E
Accumulated kW import demand
Accumulated kW export demand
Accumulated kvar import demand
Accumulated kvar export demand
Accumulated kVA demand
Series PM172 Powermeters
