GENERAL CONFIGURATION
1.

GUI Environment

The GUI is the Device interface (Graphical User Interface) used to manage the VersAtivePro transcoder, DigiVuII and DigiVuII
Micro encoders. In this manual these encoders and transcoders will be referred to as Devices since the GUI is common to
all three products.
1.1

Chapter Contents

•

"Port Opening - Switch and Firewall"

• "The GUI"
• "Application Terminology"
• "Descriptive Icons"
• "Context Sensitive Menus"
• "Copy & Paste"
• "Configuring the Device - Quick Summary"
• "Launch the GUI and Log in"
1.2 Port Opening - Switch and Firewall
NOTE: Any Management Switch used between Devices and the Management Computer will
require the following ports to be opened both Inbound and Outbound.
Port Number Transport Protocol
80
8080
8111
8112
8113
8118
1935
1935
8443
1.2.1 Notes on Opening Fire Wall Port 1935 for Monitoring
Some firewalls reject traffic that doesn't use the HTTP protocol. This behavior can prevent communication over RTMP even
if port 1935 is open. Consult the documentation for the firewall to determine how to configure it to allow RTMP traffic. To use
RTMP and RTMFP, any switch or firewall between the server and clients must allow inbound and outbound traffic on port 1935.
If it is not possible to open port 1935 inbound and outbound then monitoring will not work. In this case it is best to disable
monitoring altogether within the GUI, see Figure 1-4.
The resource contains both the actual publish and the preview. When the preview can not connect the whole pipeline of the
stream will stop and retry and not publish. The events log will report "Cannot connect to RTMP server". The resource will show
"Resource is retrying" at the events tab. Disabling 'Preview' will prevent events from being detected when the streams cannot
connect during monitoring.
VersAtive Pro, DigiVu II, DigiVu
® ®
TCP RTMP,
RTMPT,
HTTP
TCP HTTP
TCP
UDP
UDP
TCP RTMP/E
UDP RTMFP
TCP HTTPS
II Micro – Operation Manual
®
Description
File Upload (Licence, VersAtive Software) By default, Flash Player clients
make RTMP connections over port 1935 using TCP.
To communicate over the RTMP protocol, clients attempt to connect to ports
in the following order: 1935, 80 (RTMP), 80 (RTMPT).
HTTP Communications
Communication
Communications
Messaging
Communications
Adobe Flash (Previewing, Monitoring) Flash Media Server listens for
® ®
RTMP/E requests on port 1935/TCP. Flash Player and AIR clients attempt
to connect over ports in the following order: 1935, 80 (RTMP), 80 (RTMPT).
Adobe Flash (Previewing, Monitoring) Flash Media Server listens for RTMFP
requests on port 1935/UDP
HTTPS Communications
CHAPTER 1: GUI ENVIRONMENT
1-1
