MODE RIGHT button. Use this button to change the mode. The button works
only if the main screen with the indicator of currently selected mode is
displayed.
6
N :
OTE
This button will not work if the controller mode is forced by one of binary
inputs listed in the
GCB button. Works in MAN and TEST modes only. Press this button to open
or close the GCB or start synchronizing manually. Note that certain conditions
7 must be valid otherwise GCB closing resp. starting of synchronization is
blocked. See the
details.
MCB button. Works in MAN and TEST modes only. Press this button to open
or close the MCB or start reverse synchronization manually.
N :
OTE
8 Only in InteliCompact SPTM version.
C
AUTION
You can disconnect the load from the mains supply with this button! Be sure
you know well what you are about to do!
G -
EN SET OPERATION INDICATORS
P D
OSITION ESCRIPTION
General alarm. This red indicator lights if at least one alarm is present in the alarm list.
9
It blinks if a new alarm has appeared and is still not acknowledged.
Gen-set voltage OK. This green indicator lights if the generator voltage and frequency
is in limits.
10
N :
OTE
The limits for the generator voltage and frequency are given by setpoints in the Gener
Protect group.
GCB position. This green indicator blinks if the forward sychronizing is currently in
11 progress; otherwise it shows current status of the generator circuit breaker according to
the feedback input.
12 Bus under voltage. This green indicator shows if the bus is under voltage or not.
MCB position. This green indicator blinks if the reverse sychronizing is currently in
progress; otherwise it shows current status of the mains circuit breaker according to the
feedback input.
13
N :
OTE
Only in InteliCompact SPTM version.
Mains voltage OK. This green indicator lights if the mains is evaluated as healthy. See
the Reference guide
14
N :
OTE
Only in InteliCompact SPTM version.
Mains failure. This red indicator lights when the mains failure is detected and after the
gen-set has started and is about to take the load it lights permanently until the mains
failure disappears.
15
N :
OTE
Only in InteliCompact SPTM version.
D
ISPLAY AND DISPLAY CONTROL BUTTONS
I C -NT, SW
NTELI OMPACT
Reference Guide
Reference Guide
!
– "AMF function" chapter for details about mains evaluation.
