Kit Contents - Model Tech Sukhoi SU-31 Assembly Instructions Manual

kit ContentS

Before you begin assembly, group the parts as we list them below. This will ensure that you have all of the parts before you begin
assembly and it will also help you become familiar with each part.
IF YOU FINd ANY PARTS MISSING OR dAMAGEd, PLEASE CONTACT US dIRECTLY,
USING ThE CUSTOMER SERVICE INFORMATION ON PAGE 2.
airfraMe aSSeMBlieS
❑ (1) Fuselage
❑ (1) Wing with Ailerons
❑ (1) Horizontal Stabilizer with Elevator
❑ (1) Vertical Stabilizer with Rudder
Main landinG Gear aSSeMBlY
❑ (2) Aluminum Landing Gear Brackets
❑ (2) Main Gear Wheels
❑ (3) M3 x 25mm Machine Screws
❑ (2) M3 x 35mm Machine Screws
❑ (5) M3 Lock Nuts
❑ (2) Wheel Collars with Machine Screws
❑ (12) M3 Flat Washers
tail Wheel aSSeMBlY
❑ (1) Tail Wheel Wire
❑ (1) Tail Wheel
❑ (1) Landing Gear Strap
❑ (1) Wheel Spacer
❑ (1) Wheel Collar with Machine Screw
❑ (2) M3 x 12mm Wood Screws
eleVator and rudder Control SYSteMS
❑ (1) 5-1/4" (133mm) Threaded Wire with 90º Bend
❑ (1) 4-7/8" (124mm) Threaded Wire with 90º Bend
❑ (2) Control Horns with Backplates
❑ (2) Clevises
❑ (2) Snap-Keepers
❑ (4) M2 x 16mm Machine Screws
❑ (7) C/A-Style Hinges
aileron Control SYSteM
❑ (2) 3-1/4" (83mm) Threaded Wires with 90º Bends
❑ (2) Control Horns with Backplates
❑ (2) Clevises
❑ (2) Snap-Keepers
❑ (4) M2 x 16mm Machine Screws
❑ (8) C/A-Style Hinges
throttle Control SYSteM
❑ (1) 6-1/4" (160mm) Plain Wire with Z-Bend
❑ (1) Adjustable Pushrod Connector with Nut and Machine Screw
Page
