Kit Contents - Model Tech Fun Fighters P-51 ARF Assembly Instructions Manual

Before you begin assembly, group the parts as we list them below. This will ensure that you have all of the parts before you begin
assembly and it will also help you become familiar with each part.
IF YOU FIND ANY PARTS MISSINg OR DAMAgED, PLEASE CONTACT YOUR LOCAL MODEL TECH DISTRIBUTOR,
airfraMe asseMBLies
❑ (1) Fuselage
❑ (1) Right Wing Panel with Aileron
❑ (1) Left Wing Panel with Aileron
❑ (1) Horizontal Stabilizer with Elevator Halves
❑ (1) Vertical Stabilizer with Rudder
LANDINg gEAR ASSEMBLY
❑ (2) Landing Gear Wires
❑ (1) Tail Wheel Wire with Tail Wheel
❑ (2) Wheels
❑ (4) Mounting Straps
❑ (8) M3 x 12mm Wood Screws
❑ (2) Wheel Spacers
❑ (2) Wheel Collars
❑ (2) M3 x 5mm Machine Screws
ELEvATOR AND RUDDER CONTROL SYSTEM ASSEMBLIES
❑ (2) Hardwood Dowels
❑ (2) Plain Pushrod Wires
❑ (3) Threaded Pushrod Wires
❑ (3) Control Horns with Backplates
❑ (3) Clevises
❑ (2) Snap-Keepers
❑ (4) Heat-Shrink Tubing
❑ (9) M2 x 16mm Machine Screws
❑ (7) C/A-Style Hinges
aiLeron controL systeM asseMBLy
❑ (2) 3-1/8" (80mm) Threaded Pushrod Wires with 90º Bends
❑ (2) Adjustable Control Horns
❑ (2) Clevises
❑ (2) Snap-Keepers
❑ (6) C/A-Style Hinges
engine Mount asseMBLy
❑ (2) Engine Mounting Beams
❑ (4) M3 x 18mm Machine Screws
❑ (4) M3 x 25mm Socket-Cap Screws
❑ (4) M3 Lock Nuts
❑ (4) M3 Blind Nuts
❑ (12) M3 Flat Washers
throttLe controL systeM asseMBLy
❑ (1) 13" (330mm) Pushrod Wire with Z-Bend
❑ (1) Adjustable Pushrod Connector Assembly

Kit contents

using the custoMer serVice inforMation on page 2.
