Section 2: Tools And Supplies Required; Section 3: Kit Contents - Model Tech Dragon Lady Instructions For Final Assembly

SECTION 2: TOOLS AND SUPPLIES REQUIRED

The tools and supplies listed below will be necessary to finish the final assembly of your Dragon Lady 60 ARF. We suggest
having these items on-hand before beginning assembly.
Kwik Bond Thin C/A # 887500
Kwik Bond Thick C/A # 887510
Kwik Bond 5 Minute Epoxy # 887560
Kwik Bond 30 Minute Epoxy # 887565
Kwik Bond C/A Debonder # 887545
Pacer Z-42 Threadlocker # 339162
# 1 Phillips Head Screwdriver
# 2 Phillips Head Screwdriver
Dubro 5mm Drill & Tap Set # 867235
3mm Hex Wrench
Adjustable Wrench
Wire Cutters
Needle Nose Pliers
Excel Modeling Knife # 692801
Scissors

SECTION 3: KIT CONTENTS

We have organized the parts as they come out of the box for easier identification during assembly. Before you begin
assembly, group the parts as we list them below. This will ensure that you have all of the parts before you begin assembly
and it will also help you become familiar with each part. If you find any parts missing or damaged, please contact us using
the information below:
Phone: (714) 963-0329
AIRFRAME ASSEMBLIES
(1) Fuselage
(1) Right Wing Panel w/Aileron
(1) Left Wing Panel w/Aileron
(1) Horizontal Stabilizer w/Elevator
(1) Vertical Stabilizer w/Rudder
THROTTLE CONTROL SYSTEM
(1) 18-3/8" Pushrod Wire w/Z-Bend
(1) Adjustable Servo Connector Assembly
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at service@globalhobby.net
Global Services
18480 Bandilier Circle
Fountain Valley CA 92708
Fax: (714) 964-6236
Electric Drill
Assorted Drill Bits
Dubro T-Pins # 567685
Ernst Airplane Stand # 223977
Rotary Tool w/Cutting Disc & Sanding Drum
Ruler
Pencil
Waxed Paper
Builder's Triangle
220 Grit Sandpaper w/Sanding Block
Masking Tape
Paper Towels
Rubbing Alcohol
NHP Epoxy Mixing Sticks # 864204
NHP Epoxy Mixing Cups # 864205
On the Web
http://globalservices.globalhobby.com
E-mail: service@globalhobby.net
AILERON CONTROL SYSTEM
(1) Plywood Aileron Servo Tray (W22)
(2) 4-1/2" Threaded Wires w/90º Bend
(2) Nylon Adjustable Control Horns
(2) Nylon Clevises
(2) Nylon 90º Snap Keepers
(8) C/A Style Hinges
Continued On Next Page
