SECTION 4: KIT CONTENTS

We have organized the parts as they come out of the box for easier identification during assembly. Before you begin assembly,
group the parts as we list them below. This will ensure that you have all of the parts before you begin assembly and it will also help
you become familiar with each part.
If you find any parts missing or damaged, please contact us as soon as possible,
AIRFRAME ASSEMBLIES
(1) Fuselage
(1) Right Wing Panel w/Aileron
(1) Left Wing Panel w/Aileron
(1) Horizontal Stabilizer w/Elevator Halves
(1) Vertical Stabilizer w/Rudder
LANDING GEAR ASSEMBLY
(1) Aluminum Landing Gear Bracket
(2) Molded Wheel Pants
(2) Main Gear Wheels
(2) M4 x 35mm Threaded Axles
(3) M4 x 16mm Machine Screws
(4) M4 Lock Nuts
(2) Nylon Spacers
(2) M2 x 10mm Flange-Head Wood Screws
(13) M4 Flat Washers
AILERON CONTROL SYSTEM
(2) 3-1/8" Threaded Wires w/90º Bends
(2) Nylon Control Horns w/Backplates
(2) Nylon Clevises
(2) Nylon 90º Snap-Keepers
(4) M2 x 16mm Machine Screws
(8) C/A-Style Hinges
ELEVATOR CONTROL SYSTEM
(2) 6-3/8" Threaded Wires w/90º Bends
(2) Nylon Control Horns w/Backplates
(2) Nylon Clevises
(2) Nylon 90º Snap-Keepers
(4) M2 x 12mm Machine Screws
(6) C/A-Style Hinges
ENGINE MOUNT ASSEMBLY
(2) Engine Mounting Beams
(4) M4 x 20mm Socket-Cap Screws
(4) M4 x 25mm Socket-Cap Screws
(4) M4 Lock Nuts
(12) M4 Flat Washers
using the Customer Service Information on page # 3.
RUDDER CONTROL SYSTEM
(2) 38-1/2" Threaded Wires w/90º Bends
(2) Nylon Control Horns (w/o Backplates)
(2) Nylon Clevises
(2) Nylon 90º Snap-Keepers
(4) M2 x 12mm Machine Screws
(4) M2 Flat Washers
(4) M2 Hex Nuts
(3) C/A-Style Hinges
THROTTLE CONTROL SYSTEM
(1) 13-1/4" Plain Wire w/Z-Bend
(1) Adjustable Pushrod Connector w/Machine Screw & Nut
TAIL SKID ASSEMBLY
(1) Prebent Tail Skid
(2) Nylon Mounting Straps
(4) M2 x 10mm Wood Screws
FUEL TANK ASSEMBLY
(1) 320cc Fuel Tank
(1) Large Diameter Metal Plate
(1) Small Diameter Metal Plate
(1) Neck-Reinforcement Ring
(1) Rubber Stopper
(1) Fuel Pick-Up "Clunk"
(1) M3 x 20mm Machine Screw
(1) Silicone Fuel Tubing
(3) Aluminum Tubing
MISCELLANEOUS FUSELAGE PARTS
(1) Belly Pan
(1) Molded Cowling
(1) Spinner Assembly w/Backplate & Screws
(1) Molded Canopy
(4) M3 x 5mm Wood Screws
(1) Clear Vinyl Tubing
(1) Decal Set
6 Continued On Next Page
