SECTION 2: TOOLS AND SUPPLIES REQUIRED

The tools and supplies listed below will be necessary to finish the assembly of your Modeltech SE5a Scout ARF. We
suggest having these items on hand before beginning assembly.
Kwik Bond Thin C/A # 887500
Kwik Bond Thick C/A # 887510
Kwik Bond 5 Minute Epoxy # 887560
Kwik Bond 30 Minute Epoxy # 887565
Kwik Bond C/A Debonder # 887545
Pacer Formula 560 Canopy Glue # 339176
Pacer Z-42 Blue Threadlocker # 339162
# 1 & # 2 Phillips Head Screwdrivers
2.5mm Hex Wrench
Adjustable Open-End Wrench
Wire Cutters
Needle Nose Pliers
Excel Modeling Knife # 692801
Scissors
Electric Drill

SECTION 3: KIT CONTENTS

We have organized the parts as they come out of the box for easier identification during assembly. Before you begin
assembly, group the parts as we list them below. This will ensure that you have all of the parts before you begin assembly
and it will also help you become familiar with each part.
If you find any parts missing or damaged, please contact us at:
Phone: (714) 963-0329
AIRFRAME ASSEMBLIES
(1) Fuselage
(1) Top Wing w/Ailerons
(1) Bottom Wing w/Ailerons
(1) Horizontal Stabilizer w/Elevator
(1) Vertical Stabilizer w/Rudder
THROTTLE CONTROL SYSTEM
(1) 16" Pushrod Wire w/Z-Bend
(1) Adjustable Servo Connector Assembly
Global Services
18480 Bandilier Circle
Fountain Valley CA 92708
Fax: (714) 964-6236
Assorted Drill Bits
Dubro T-Pins # 567685
Ernst Airplane Stand # 223977
Robart Incidence Meter # 561554
Rotary Tool w/Cutting Disc & Sanding Drum
Ruler
Pencil
Builder's Triangle
220 Grit Sandpaper w/Sanding Block
Masking Tape
Paper Towels
Rubbing Alcohol
NHP Epoxy Mixing Sticks # 864204
NHP Epoxy Mixing Cups # 864205
On the Web
http://globalservices.globalhobby.com
Email: service@globalhobby.net
FUEL TANK ASSEMBLY
(1) 240cc Fuel Tank
(1) Large Diameter Metal Plate
(1) Small Diameter Metal Plate
(1) Metal Neck-Reinforcement Ring
(1) Rubber Stopper
(1) Fuel Pick-Up "Clunk"
(1) M3 x 20mm Machine Screw
(1) Silicon Fuel Tubing
(2) Aluminum Tubing
