Table 2: Installer Configuration Menu (Part 2 of 6)
Parameter Description and Default
Appearing
on Display
MenuScro Gives the option of having the
display continuously scroll the
parameters.
Default: on
Lockout Selectable Lockout Levels for
limiting end-user keypad interaction.
Default: 0
3 Sets the delay time period at
Pwr del
controller powerup, or each time
power is removed and reapplied,
before any operation (fan, heating,
or cooling) is authorized. Also can
be used to sequence the startup of
multiple units in one location.
Default: 10.0 sec
Frost pr Provides a minimum heating
setpoint of 42.0°F/5.5°C to prevent
freezing in the zone controlled by
the controller.
Default: off
4 Sets the Occupied and Unoccupied
Heat max
maximum Heating setpoint values.
Default: 90.0°F/32.0°C
4 Sets the Occupied and Unoccupied
Cool min
minimum Cooling setpoint values.
Default: 54.0°F/12.2°C
T606MSx-4 and T606MSx-4+PIR Series Multi-Stage Temperature and Humidity Controllers
Installation Instructions
Selection Options
(off): The scroll is inactive.
(on): The scroll is active.
Function
(0)
Occupancy Access
Override
Permanent Access
Temperature
Setpoints
Temporary Access
Temperature
Setpoints
Humidity Access
Setpoints
System Mode Access
Setting
Fan Mode Setting Access
Schedules Access
2
Setting
Access
2
Clock Setting
2 Access
Permanent Hold
Range: 10.0 to 120.0 sec
(on): Enabled
(off): Disabled
Range: 40.0°F/4.5°C to 90.0°F/32.0°C
Range: 54.0°F/12.2°C to 100.0°F/37.7°C
Lockout Level
(1) (2)
Access No Access
No Access No Access
Access No Access
No Access No Access
No Access No Access
No Access No Access
No Access No Access
Access Access
No Access No Access
9
