Wiring
When an existing controller is replaced, remove and
label the wires to identify the terminal functions. When
a T606MSx-4 or T606MSx-4+PIR Series Controller is
replaced, simply remove the old screw terminal blocks
and reinsert them onto the PCB of the replacement
controller.
CAUTION: Risk of Electric Shock.
Disconnect power supply before making
!
electrical connections to avoid electric
shock.
CAUTION: Risk of Property Damage.
! Do not apply power to the system before
checking all wiring connections. Short
circuited or improperly connected wires
may result in permanent damage to the
equipment.
IMPORTANT: Make all wiring connections in
accordance with local, national, and regional
regulations. Do not exceed the electrical ratings of
the T606MSx-4 or T606MSx-4+PIR Series
Temperature and Humidity Controller.
To wire the controller:
1. Strip the ends of each wire 1/4 in. (6 mm) and
connect them to the appropriate screw terminals as
indicated in Figure 5.
2. Carefully push any excess wire back into the wall.
Note: Seal the hole in the wall with fireproof
material to prevent drafts from affecting the
ambient temperature readings.
3. Reinsert the screw terminal blocks onto the PCB. If
multiple wires are inserted into the terminals, be
sure to properly twist the wires together prior to
inserting them into the terminal connectors.
4. For PIR models, carefully reattach the PIR
connector to the PCB.
5. Reattach the controller cover to the mounting base
(top side first).
6. Use a Phillips-head screwdriver to install the
security screw on the bottom of the controller cover
if desired. The security screw comes packaged
separately in a plastic bag with the controller.
T606MSx-4 and T606MSx-4+PIR Series Multi-Stage Temperature and Humidity Controllers
Installation Instructions
Five-Pole
Left Top Connector
Y2 Y1 G RC
3 4
1 2
Eight-Pole Bottom Connector
DE
HUM AUX
DI
HUM
9 10 11 12
Figure 5: Terminal Blocks
Table 1: Terminal Identification (See Figure 5.)
Number Label
1 1
Y2
2 1
Y1
3 1
G
4 RC
5 C
6 RH
7 2
W1
8 2
W2
9 HUM
10
1
AUX
11 DEHUM
12 DI
13 HS
14 SCOM
15 OS
16 HL
1. Provides the voltage from RC through a relay contact.
2. Provides the voltage from RH through a relay contact.
Three-Pole
Right Top
C
Connector
5
RH
W1 W2
6 7 8
S
HS OS HL
COM
15
13 14 16
Function
Energizes on a Call for
Second-Stage Cooling
Energizes on a Call for
First-Stage Cooling
Energizes Fan in Accordance
with Selected Fan Mode
24 VAC from Equipment
Transformer
24 VAC (Common) from
Equipment Transformer
24 VAC for Heating Stage
Energizes on a Call for
First-Stage Heating
Energizes on a Call for
Second-Stage Heating
Humidity Output
Auxiliary Output
Dehumidification Output
Configurable Digital Input
0–10 VDC Remote Humidity
Sensor
Sensor Common
Outside Air Temperature Sensor
0–10 VDC High Limit Humidity
Sensor
3
