Table 10: Four-Event Office Schedule
Event
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
1. Programming different events to the same time for that day cancels those events and leaves the controller in the
Unoccupied state.
Setting the Day and Time (T606MSP-4 and
T606MSP-4+PIR Models)
Upon initial powerup (or after a power loss of greater
than 6 hours), a SetClock alarm appears on the
controller display. As the controller scrolls through the
Status Display Menu, the SetClock alarm message
causes the backlight to light up until the clock is set.
When changing the time, press and release the
UP/DOWN arrow keys once to change the time in
1-minute increments; press and hold down the keys to
change the time in 30-minute increments.
To set the day and time, follow the steps in Table 11:
Table 11: Setting the Day and Time (Part 1 of 2)
Controller Description
Display
Press the MENU key while in the
Status Display Menu to enter the
RoomTemp
Main User Menu.
75.0 ° F
Press the NO key for all prompts until
the clock set prompt appears on the
Clock
display. Press the YES key to enter
set? Y/N
the clock set menu.
Press the YES key to set the time or
press the NO key to advance to the
Time
day set menu.
set? Y/N
T606MSx-4 and T606MSx-4+PIR Series Multi-Stage Temperature and Humidity Controllers
Installation Instructions
Event 1
Occupied
Cool Heat Cool
72°F 70°F 80°F
(22°C) (21°C) (27°C)
7:00 A.M.
7:00 A.M.
7:00 A.M.
7:00 A.M.
7:00 A.M.
1
12:00 P.M.
1
12:00 P.M.
Event 2
Unoccupied Occupied 2
Heat Cool
62°F 72°F
(17°C) (22°C)
5:00 P.M.
12:00 P.M.
5:00 P.M.
12:00 P.M.
5:00 P.M.
12:00 P.M.
5:00 P.M.
5:00 P.M.
1
12:00 P.M. 12:00 P.M.
1
12:00 P.M. 12:00 P.M.
Table 11: Setting the Day and Time (Part 2 of 2)
Controller
Display
Time
0:00
Day
set? Y/N
Day
Monday
12/24hrs
set? Y/N
12/24hrs
12 hrs
Exit?
Y/N
Event 3 Event 4
Unoccupied 2
Heat Cool
70°F 80°F
(21°C) (27°C)
1
12:00 P.M.
1
12:00 P.M.
1
12:00 P.M.
7:00 P.M. 10:30 P.M.
7:00 P.M. 10:30 P.M.
1
12:00 P.M.
1
12:00 P.M.
Description
Press the UP/DOWN arrow keys to
adjust the time. When the correct
time is displayed, press the YES key
to store the time.
Press the YES key to enter the day
set menu or press the NO key to
enter the clock format menu.
Press the UP/DOWN arrow keys to
adjust the day. When the correct day
is displayed, press the YES key to
store the day.
Press the YES key to choose the
time format or press the NO key to
access the Main User Menu exit
prompt.
Press the UP/DOWN arrow keys to
select the desired time format. Press
the YES key to enter the format.
Press the YES key to return to the
Status Display Menu or press the NO
key to return to the time set menu.
Heat
62°F
(17°C)
1
1
1
1
1
