Technical Specifications

T606MSx-4 and T606MSx-4+PIR Series Temperature and Humidity Controllers
Power Requirements
Relay Contact Rating (Y2, Y1, G, W1,
W2, and AUX)
Digital Inputs
Humidification Analog Output
Rating
Wire Size
Temperature Sensor Type
Temperature Range Backlit
Display
Heating
Control
Cooling
Control
Accuracy Temperature
Humidity
Minimum Deadband
Ambient Conditions Operating
Storage
Compliance United States
Canada
Europe
Australia and
New Zealand
Shipping Weight
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or
misuse of its products.
22 T606MSx-4 and T606MSx-4+PIR Series Multi-Stage Temperature and Humidity Controllers
Installation Instructions
Published in U.S.A.
19 to 30 VAC, 50/60 Hz, 2 VA (Terminals RC and C) at 24 VAC Nominal, Class 2 or
Safety Extra-Low Voltage (SELV)
19 to 30 VAC, 1.0 A Maximum, 15 mA Minimum 3.0 A Inrush, Class 2 or SELV
Voltage-Free Contacts across Terminal C to Terminal DI
0 to 10 VDC into 2k ohm Resistance Minimum
18 AWG (1.0 mm Diameter) Maximum, 22 AWG (0.6 mm Diameter) Recommended
Local 10k ohm Johnson Controls Type II Negative Temperature Coefficient (NTC)
Thermistor Sensor
-40.0°F/-40.0°C to 122.0°F/ 50.0°C in 0.5° Increments
40.0°F/4.5°C to 90.0°F/32.0°C
54.0°F/12.0°C to 100.0°F/38.0°C
±0.9F°/±0.5C° at 70.0°F/21.0°C Typical Calibrated
±5% RH from 30 to 70% RH at 50 to 90°F (10 to 32°C)
2F°/1C° between Heating and Cooling
32 to 122°F (0 to 50°C); 95% RH Maximum, Noncondensing
-22 to 122°F (-30 to 50°C); 95% RH Maximum, Noncondensing
UL Listed, File E27734, CCN XAPX,
Under UL 873, Temperature Indicating and Regulating Equipment
FCC Compliant to CFR 47, Part 15, Subpart B, Class A
UL Listed, File E27734, CCN XAPX7,
Under CAN/CSA C22.2 No. 24, Temperature Indicating and Regulating Equipment
Industry Canada, ICES-003
CE Mark – Johnson Controls, Inc., declares that this product is in compliance with
the essential requirements and other relevant provisions of the
EMC Directive 2004/108/EC.
C-Tick Mark, Australia/NZ Emissions Compliant
T606MSx-4 Models: 0.75 lb (0.34 kg)
T606MSx-4+PIR Models: 0.77 lb (0.35 kg)
