Table 2: Installer Configuration Menu (Part 5 of 6)
Parameter Description and Default
Appearing
on Display
Unocc TM Sets the time delay between the
moment when the controller toggles
from the Occupied mode to the
Unoccupied mode after the last
motion is detected by the
occupancy sensor.
Default: 0.5 hours
2 Sets the number of events within a
2/4event
24-hour period.
Default: 2.0
Aux cont Energizes peripheral devices
(lighting equipment and exhaust
fans).
Default: n.o.
Note: The contact toggles with the
internal Occupied/Unoccupied
schedule (or the NSB contact on
one of the digital inputs, if used).
2 Provides the desired occupied
Prog rec
temperature either at the start of the
Occupied schedule or after the
Occupied schedule begins.
Default: off
Note: Progressive recovery is
disabled if DI is configured as
remote NSB.
5 Sets minimum outside air
RH LT
temperature for RH setpoint reset.
Default: -20°F/-29°C
RH HT Sets maximum outside air
temperature for RH setpoint reset.
Default: 32°F/0°C
HL Sp Sets high humidity level setpoint
when 0 to 10 VDC sensor is
connected at the controller.
Default: 85% RH
5 Sets outside air temperature under
Dhu OALK
which dehumidification operation is
disabled.
Default: 32°F/0°C
Dhu LCK Enables or disables
dehumidification lockout control.
Default: On
DehuHyst Controls dehumidification hysteresis
when dehumidification sequence is
enabled.
Default: 5% RH
12 T606MSx-4 and T606MSx-4+PIR Series Multi-Stage Temperature and Humidity Controllers
Installation Instructions
Selection Options
Range: 0.5 hours to 24.0 hours adjustable in 0.5 hour increments
(4.0): Four events (two Occupied and two Unoccupied) within a
24-hour period
(2.0): Two events (one Occupied and one Unoccupied) within a
24-hour period
(n.c.): Contact open = Occupied; contact closed = Unoccupied
(n.o.): Contact closed = Occupied; contact open = Unoccupied
(on): Enabled (provides the desired occupied temperature at the
start of the Occupied schedule)
(off): Disabled (provides the desired occupied temperature after the
Occupied schedule begins)
Range: -40°F/-40°C to 15°F/-9.5°C
Range: 20°F/-6.5°C to 55°F/13°C
Range: 50 to 90% RH
Note: Feature is automatically disabled if no sensor is connected to
the controller
Range: -40°F/-40°C to 122°F/50°C
(On): Dehumidification operation is restricted based on the following
conditions:
• System mode must be Cool or Auto
• Low ambient room temperature protection is enabled
(Off): Dehumidification process not restricted, the following
conditions are present:
• System mode must be Cool, Heat or Auto
• Ambient room temperature protection is not enabled
Range: 2 to 20% RH
