To record every parameter set under a location, highlight the
•
location and press

Saving Recordings

When you are in the Record Review Menu you have several options
for saving your recordings.
Auto Save
The instrument momentarily displays the recorded information
on-screen before returning you to the Record Review Menu.
Record/Review
The instrument pauses after each recording so that you can review it
on-screen.
To take the next recording press
•
you to the Record Review Menu or, if you have selected a
location with multiple parameter sets underneath it, begin
taking the next recording.
Free Run, Manual Save
The instrument will continuously record the signal and update the
on-screen display.
To stop measuring press
•
To record the next parameter set without saving this
•
recording press
Review Menu or, if you have selected a location with multiple
parameter sets underneath it, begin taking the next
recording.

Reviewing Recordings

To review recordings immediately after taking them you can set the
instrument's save option to Record/Review; to do this, from the Main
Menu press
to begin recording.
This will either return you to the Record
Review Vibration then press
This will either return
To save the recording press
repeatedly until
Section 9: Taking Recordings 91
