To stop the measurement press
•
the measurement on-screen, including displaying the
amplitude of spectral peaks and identifying harmonics (see
Analyzing Measurements).
OR
To stop viewing the measurement and exit without saving
•
press
OR
To save the measurement press
•
machine location or create a new one (see Saving
Measurements on page 71).
Changing the default settings
To change any of the settings shown on the right of the
•
screen, press the keys beside the on-screen icons.
To change any of the settings shown at the bottom of the
•
screen press
icons. Pressing keys causes the display to cycle through the
available options or opens a sub-menu where you can enter
a value or choose a value from a list.
Pressing
If a sub-menu opens, make your changes then press
•
This will apply your settings and return you to the previous
menu where you can change further settings if required.
then press the keys beside the on-screen
lets you change the measurement setup
Section 6: Analyzing Measurements Onsite
You can now analyze
and select an existing
