Section 7: Setting Measurement
Options
This section describes the different parameters used to take
measurements and how to apply them.
You will learn:
What the various parameters are for spectra, waveforms and
•
other measurement types
How to create parameter sets for taking measurements
•
What measurement units and overall scaling options are
•
available
How to assign sensors to channels
•
Setting Measurement Units and
Spectrum Scaling
You can choose the standard US or SI units, or choose your own
preferences. The table below summarizes the options.
To set a preference, from the Main Menu press
•
Options then press
Press
•
To set your own preferences select Custom then press the
keys beside the first option you wish to change.
Most on-screen options will open a sub-menu; press the
•
keys repeatedly to cycle through the various options. When
you have finished press
Measurement Units Menu.
Measuring Units.
repeatedly to toggle which unit set is displayed.

Section 7: Setting Measurement Options

to save and return to the
