Using Cursors

Cursors are a valuable tool for analyzing your data. You can use
them to show the amplitude and frequency of a peak, identify
harmonics, and show the frequency difference between two peaks.
Placing a cursor on the chart
Press
•
it across the screen. To move the cursor rapidly from peak to
peak within a displayed waveform recording press and hold
the key.
Placing a second cursor on the chart
Press
•
immediately visible as it will be placed directly behind the
first cursor (the new cursor's values will appear at the top
right of the screen).
Press
•
side so that it becomes visible.
Toggling the active cursor
Press
•
cursors.
Pressing displays analysis options
or repeatedly to activate a cursor and move
Second Cursor. The second cursor will not be
or repeatedly to move the cursor to either
Second Cursor to toggle between the two
Section 6: Analyzing Measurements Onsite 63
