LED Indicators
Five LED indicators located on the instrument's front panel indicate
the instrument's current state and warn of measurement problems.
Power supply (GREEN)
Charging (RED)
Danger (RED)
Alert (AMBER)
OK (GREEN)
Instrument LEDs
Illuminates when power is supplied to the
instrument from the power adapter.
Indicates that the instrument battery is
charging.
Illuminates when a DSP or critical error
occurs.
Not
used
on
models.
Indicates that a measurement is being, or
has been, collected successfully (without an
error or alert triggered).
vbBalancer
instruments
Section 1: Introduction
11
