  • Page 1 X8 Rental Display Installation manual R5905160/03 25/02/2013...
  • Page 2 Barco nv LiveDots President Kennedypark 35, B-8500 Kortrijk Phone: +32 56.23.32.11 Fax: +32 56.26.22.62 Support: www.barco.com/esupport Visit us at the web: www.barco.com Printed in Belgium...

  • Page 3: Disposal Information

    The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of complaint, Barco can repair the fault or provide a replacement at its own discretion within an appropriate period.
  • Page 4 Normal wear as well as normal maintenance are not subject to the guarantee provided by Barco either. The environmental conditions as well as the servicing and maintenance regulations specified in the this manual must be complied with by...

  • Page 5: Table Of Contents

    5. X8 rental peripherals and accessories ..............
  • Page 6 Index........................91 R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 7: Safety

    Read this chapter attentively. It contains important information to prevent personal injury while installing your X8 rental display. Fur- thermore, it includes several cautions to prevent damage to the X8 tile. Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing the X8 rental display.

  • Page 8: Safety Guidelines

    Structural & mounting components should be kept dry, clean, lubricated (only if recommended), coated properly, and otherwise maintained in a manner consistent with part design. Barco products must be used in a manner consistent with their design and inspected on a routine basis for security, wear, deformation, corrosion and any other circumstances that may affect the load handling capability of the part.

  • Page 9: Important Safety Instructions

    Use only with systems or peripherals specified by the manufacturer, or sold with the apparatus. Use caution during lifting/moving or transporting to avoid damage by possible tipping. • Do not use damaged goods. Replace damaged parts immediately. R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 10: Important Warnings

    Each power source cable supplying maximum 4 X8 Connection Boxes should be protected by a circuit breaker or fuses rated 16 A / 250 VAC (15 A / 250 VAC in the USA and Canada). Note that one X8 Connection Box requires 200-240 VAC, 50-60 Hz, 3.6 amps at 200 VAC.
  • Page 11 1. Safety Do not install a base stand X8 display upon a smooth surfaces. Place rubber mats between the foot beams of the LED wall and the smooth surface to increase friction. Maximum wind load for hanging configuration The X8 display in a hanging configuration must be torn down in case winds exceeds Beaufort force 6 (>50km/hr).

  • Page 12: Proper Usage

    Safety and functional features of the display cannot be defeated. • It is not allowed to climb or hang any additional equipment on the back of an X8 wall. Nothing is to be allowed to hang from the cables of an X8 tile.

  • Page 13: Important Warnings Concerning Flight Cases

    Important warnings concerning flight cases Important warnings concerning stack and transport X8 rental flight cases • Maximum stack two (2) flight cases with X8 Rental Tiles high and three (3) flight case with X8 feet/truss accessories high. Never higher. •...
  • Page 14 1. Safety R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 15: Installation Requirements

    2. Installation requirements 2. INSTALLATION REQUIREMENTS About this chapter This chapter enumerates the mechanical requirements for the X8 display, the electrical requirements to power up the X8 display and the system requirements to run the control software efficiently. Overview •...

  • Page 16: Mechanical Requirements For The X8 Rental Display

    Do not underestimate the weight of a complete X8 rental display. Be sure that the floor or truss installation on which the X8 rental display has to be installed is capable of handling five (5) times the complete load of the display. Note that one X8 rental tile weighs approximately 40 kg (or 41 kg per square meter display).

  • Page 17: Electrical Requirements For The X8 Rental Display

    Power requirements One X8 Connection Box requires 200-240 VAC, 50-60 Hz, 3.6 amps at 200 VAC Note that one X8 Rental Tile correspond with a display surface of 0.97 m². Power split cables are used to link the power from X8 Connection Box to X8 Connection Box. However, MAXIMUM 4 X8 Connection Boxes may be connected in parallel.

  • Page 18: System Requirements For The Director Toolset

    PC Pentium IV or equivalent, 2.4 GHz 1 Gb RAM 300 Mb hard disk free space SXGA resolution (1280 x 1024) with 32 Mb video memory Serial communication port Ethernet connection • Software Windows XP Professional, Windows Vista or Windows 7 R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 19: System Overview

    3. System overview 3. SYSTEM OVERVIEW About this chapter This chapter enumerates the fundamental elements of the X8 rental display. Overview • Introduction R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 20: Introduction

    The fundamental elements of an X8 rental display system are: • X8 rental tile (includes modules, X8 Connection Box and frame). • X8 rental feet, foot beams and stacker or X8 rental truss beams • Rental power box. • Digitizer.

  • Page 21: Components Of A X8 Rental Tile

    General introduction The X8 rental tile has a rugged frame where X8 modules fit into to form one display tile. These modules are connected via a cable string with theX8 Connection Box mounted inside the X8 rental frame. The X8 Connection Box has a HDMI input and output port to connect the X8 rental tile with the neighboring tiles in the display.

  • Page 22: X8 Rental Frame

    The X8 rental frame is made out of aluminium profiles and stainless steel to reduce weight without losing strength. This strong frame allows you to build X8 LED-walls up to 3 frames high stacked or 13 tiles high trussed. The front of the X8 rental frame has a grid where X8 modules fit in forming 3 rows of 3 modules in a chain.

  • Page 23: X8 Module

    Introduction X8 Module The front of the X8 module consists of a matrix of full color SMD LED’s enclosed by shaders and sheltered in a light weight housing. The rear of the X8 module is equipped with two positioning pins and two latches which enable a precise and fast attachment into the support grid.
  • Page 24 4. Components of a X8 Rental Tile Image 4-6 Image 4-7 X8 Module dummy data plug. X8 Module dummy power plug. R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 25: X8 Connection Box

    Using an X8 Connection Box as stand alone re-sync unit The X8 Connection Box acts like a stand alone re-sync unit in case no power is applied to the power input socket of the X8 Connection Box. When you use the X8 Connection Box as stand alone re-sync unit ensure to place dummy plugs upon the power input and...
  • Page 26 Box, and from X8 Connection Box to X8 Connection Box. See secured Barco website for complete (up-to-date) list of the different types. Note that the power output port of the last X8 Connection Box in the power chain has to be sealed with a dummy power plug.

  • Page 27: X8 Rental Peripherals And Accessories

    5. X8 rental peripherals and accessories 5. X8 RENTAL PERIPHERALS AND ACCESSORIES About this chapter This chapter describes, or refer to another manual, all the peripherals and accessories, which can be used in the setup of an X8 rental display. Overview •...

  • Page 28: X8 Rental Base Stand Setup Accessories

    X8 rental tiles. The maximum height of a base stand X8 rental display is 3 tiles high. The rental foot covers a width of one X8 tile. The X8 rental foot has the same locking mechanism as the X8 rental frames.

  • Page 29: X8 Rental Truss Setup Accessories

    X8 truss beams are required to set up the X8 rental display in a hanging configuration. Barco offers two sizes of X8 truss beams, namely the “X8 single truss beam” and the “X8 dual truss beam”. The single truss beam covers a width of one X8 tile and the dual truss beam covers two tiles.

  • Page 30: X8 Rental Flight Cases

    X8 rental flight case for X8 truss beams and/or rental feet This X8 rental flight case is multifunctional. It can hold 4 X8 rental feet, or 4 X8 single truss beams, or 2 X8 dual truss beams, or a combination of rental feet and truss beams. To make the flight case easy to handle it is provided with castor wheels, handles and stacking dishes.

  • Page 31: Dx-700 Digitizer

    • Next generation LED products such as the X8 tiles are supported via the NNI interface on the system’s NNI Output Module. Image processing and LED wall configuration and control functions are adjusted from Barco’s Director toolset, or via controls on the DX-700 digitizer front panel itself.

  • Page 32: Power Boxes

    Power boxes General To ensure safe and reliable operation of the X8 display a suitable system for AC power distribution must be used. Though 3 party solutions may be used, several sizes and types of power distributions are available from Barco. For smaller system the “Mono Phase Power Box”...

  • Page 33: Control Software

    General The control software is designed as a graphic user interface (GUI) and can be used to control and configure the digitizer as well as the Barco LED wall via a PC (e.g. Director toolset). Minimum required software version: 2.07 Image 5-9 Control software “Director toolset”.

  • Page 34: Fiberlink System

    If the distance between the digitizer and the LED-wall exceeds 10 meters, a fiber optic connection must be used to ensure signal integrity and system reliability. Barco offers a complete system solutions including transmitter, fiber and receiver. The choice of system depends on the length of cable required.

  • Page 35: Setup Process Of A X8 Rental Display

    Floor mount or hanging X8 rental display The X8 rental tiles can be used in a floor mount or in a hanging rental configuration. These configurations are limited in height, maximum 3 tiles high for a floor mount and maximum 13 tiles high for a hanging configuration. Furthermore, a floor mount (base stand) configuration can only be used indoor and must be equipped with a stacker support system at the rear of the display.

  • Page 36: Set Up A Floor Mount X8 Rental Display

    Image 6-1 2. The second stage in the process is the installation of the X8 rental tiles upon the rental feet. See detailed procedure "Installing the X8 rental tile upon the X8 rental foot", page 43 and "Installing the X8 rental tile", page 45.
  • Page 37 6. Setup process of a X8 rental display Image 6-2 Image 6-3 Image 6-4 3. The next stage is the installation of stacker system. See procedure "Installing the X8 stacker system", page 47. R5905160 X8 RENTAL DISPLAY 25/02/2013...
  • Page 38 Each power source cable supplying maximum 4 X8 Connection Boxes should be protected by a circuit breaker or fuses rated 16 A / 250 VAC (15 A / 250 VAC in the USA and Canada). Note that one X8 Connection Box requires 200-240 VAC, 50-60 Hz, 3.6 amps at 200 VAC.

  • Page 39: Set Up A Hanging X8 Rental Display

    1. The first stage in the process is the installation of the truss beams on the truss installation. 2. The second stage in the process is attaching a first row of X8 rental tiles with the truss beams to form one solid row. See chapter "Installing the X8 truss beam", page 49.
  • Page 40 Each power source cable supplying maximum 4 X8 Connection Boxes should be protected by a circuit breaker or fuses rated 16 A / 250 VAC (15 A / 250 VAC in the USA and Canada). Note that one X8 Connection Box requires 200-240 VAC, 50-60 Hz, 3.6 amps at 200 VAC.
  • Page 41 6. Setup process of a X8 rental display 7. Apply power to the X8 rental display and start up the control software. For more information about showing content on the X8 display see manual of the Director toolset. Image 6-9 ARNING The maximum height of a hanging X8 rental display is 13 tiles high.
  • Page 42 6. Setup process of a X8 rental display R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 43: Basic Setup Procedures

    About this chapter This chapter contains all installation procedures necessary to handle the X8 rental tiles, to set up an X8 rental display and to remove the X8 rental tiles from an X8 rental display. These procedures describe, with detailed step by step actions and illustrations, how to install an X8 rental display in a floor mount or hanging configuration.

  • Page 44: Installing An Adjustable Foot

    6. Adjust the height of the adjustable feet to level out the foot beam. 7. Place supporting blocks underneath the foot beam every 50 centimeters. This to prevent that the foot beam bends. Caution: Never let the complete weight of the rental display rest on the adjustable foot. R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 45: Installing The X8 Rental Feet

    How to install the X8 rental feet? 1. Place two foot beams (reference 1 image 7-2) parallel per X8 rental foot on a flat surface. 2. Attach two rental foot rails (reference 3 image 7-2) to the rental foot (reference 2 image 7-2) loosely, using four M12 x 20 mm bolts (reference 4 image 7-2).
  • Page 46 It is the responsibility of the installer to ensure the stability of the LED wall. Note that the stability of the LED wall depends on different parameters like: wind-force, weight of display, height of display, width of display, length of used foot beams and position of LED wall on foot beams (front - middle ?). R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 47: Installing The X8 Rental Tile Upon The X8 Rental Foot

    7. Basic setup procedures Installing the X8 rental tile upon the X8 rental foot How to install the X8 rental tile upon the X8 rental foot? 1. Ensure that the rental foot is installed well to support the rental tiles.
  • Page 48 9. Repeat this procedure from step 1 until all rental tiles of the first row are installed upon the rental feet. Caution: Ensure that all rental tiles in the row are sideways locked with each other. R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 49: Installing The X8 Rental Tile

    No tools. How to install the X8 rental tile in to the LED-wall? 1. Check if all locking mechanisms of the X8 rental tile are open: the two clamps at the top of the rental tile must be open. the clamp at the right side of the rental tile (seen from the rear of the rental tile) must be open.
  • Page 50 7. Fasten the two lock handles (reference 2image 7-7) at the vertical adjoining edge. Push the handle inwards and turn quarter turn clockwise. Caution: Ensure that the side pins of the neighboring tile are captured by the locking handles! 8. Fasten the clamp at the vertical adjoining edge (reference 3image 7-7). Image 7-7 R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 51: Installing The X8 Stacker System

    Two M10 x 16 mm bolts per rental foot (hexagon socket). How to install the X8 stacker system? 1. Unlock the upper telescopic stacker profile (reference 2 image 7-8) from the base of the rental foot. Do this by removing the two lock pins (reference 1 image 7-8) .
  • Page 52 7. Basic setup procedures Image 7-10 6. Repeat this procedure now for the lower telescopic stacker profile (reference 3image 7-8) and then do this for all rental feet. Image 7-11 R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 53: Installing The X8 Truss Beam

    2. Lower the X8 truss beam upon the tile(s). Ensure the all lock handles (reference 1 image 7-12) of the truss beam are in open position. As a result the locking handles at the truss beam latches and capture the mounting pins of the rental tile(s).
  • Page 54 (reference 1 image 7-15) and secure this position with two spring cotters (reference 2 image 7-15). Image 7-15 8. Repeat this procedure until all truss beams are installed and all rental tiles in the first row are sideways locked with each other. R5905160 X8 RENTAL DISPLAY 25/02/2013...
  • Page 55 7. Basic setup procedures AUTION Ensure that all rental tiles and truss beams are sideways locked with each other. R5905160 X8 RENTAL DISPLAY 25/02/2013...
  • Page 56 7. Basic setup procedures R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 57: Cabling Of The X8 Display

    8. Cabling of the X8 display 8. CABLING OF THE X8 DISPLAY About this chapter This chapter describes the power and data cabling from X8 Connection Box to X8 Connection Box and from X8 Connection Box to the X8 modules. ARNING The input and output sockets of the X8 Connection Box can only be used in conjunction with Barco’s outdoor cables for X8 LED-walls.

  • Page 58: Power Cabling Of The X8 Display

    Example of power cabling The example below shows the power cabling of a four by eight X8 display. The power box (1) is connected via a multi power cable (2) with a spider connector (3). Each spider output cable leads to a column of 4 X8 Connection Boxes. The power connection in this column is realized with a power linking cable (4).
  • Page 59 8. Cabling of the X8 display Image 8-1 R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 60: Data Cabling Of The X8 Display

    Example of data cabling The example below shows the data cabling, seen from the rear of the X8 display of four frames wide and six frames high. The data path is realized in a horizontal direction and starts in the lower left corner (seen from the rear). The settings in the control software refer to the display seen from the front.

  • Page 61: Interconnection Between X8 Connection Box And X8 Modules

    Interconnection diagram One X8 Connection Box drives 9 X8 Modules in a 3 x 3 configuration. Power and data are separately applied per row of three X8 Modules using customized power and data cable strings. Power and data of the upper row X8 Modules must be connected with the power output port 1 and data output port 1.
  • Page 62 8. Cabling of the X8 display R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 63: Maintenance

    9. Maintenance 9. MAINTENANCE Overview • Cleaning the X8 display R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 64: Cleaning The X8 Display

    Why cleaning X8 tiles? Due to outdoor use the X8 tiles are exposed to all kinds of weather conditions. Sand, dust, smog and other dirt adhere on the X8 tiles and because of that the performance of the X8 tiles can be reduced. That’s why cleaning the X8 tiles is recommended at regular intervals.

  • Page 65: Servicing

    10. Servicing 10. SERVICING Overview • Safety instructions • X8 Connection Box diagnostic • Replacing the X8 Connection Box • Replacing a X8 module • Updates R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 66: Safety Instructions

    No other parts than Barco parts are allowed. • Both hands must be free for servicing X8 tiles in an LED-wall. Therefore the use of a ladder to access a tile is forbidden. Only the use of a scaffold or a Z-lift is allowed.

  • Page 67: X8 Connection Box Diagnostic

    10. Servicing 10.2 X8 Connection Box diagnostic Boot-loader diagnostics The diagnostic segment display consist in four digits (4 x 14 segment) (reference A, B, C & D image 10-1) Image 10-1 The Star boot-loader displays diagnostics on two digits (B & D) on the segment display: •...

  • Page 68: Replacing The X8 Connection Box

    Image 10-2 5. Remove the X8 Connection Box by lifting it up a bit and hooking it out of the two mounting pins (reference 2 image 10-3) at the top of the mounting plate. Image 10-3...
  • Page 69 10. Servicing Image 10-4 6. Replace the X8 Connection Box from the mounting plate. Do this by loosing/fastening the four screws at the rear side of the mounting plate as illustrated. R5905160 X8 RENTAL DISPLAY 25/02/2013...
  • Page 70 10. Servicing Image 10-5 7. Install the mounting plate with new X8 Connection Box back in the rental frame. Secure the mounting plate by fasten the two thumbscrews (reference 1 image 10-2). 8. Reconnect all the cable strings with the X8 Connection Box.

  • Page 71: Replacing A X8 Module

    10. Servicing 10.4 Replacing a X8 module How to replace a X8 module? 1. Read and heed the servicing safety instructions. 2. Disconnect the power and data cable string from the module. 3. Release the module from the frame by turning both latches at the rear side of the module 270° clockwise (reference 1 image 10-6).

  • Page 72: Updates

    10.5 Updates my.barco.com • All product related information can be found on my.barco.com (registration required). • The latest software and firmware can be downloaded and the procedure on how to install these can be found in the Director Toolset manual.

  • Page 73: Dimensions

    Dimensions of the X8 Single Truss Beam • Dimensions of the X8 Dual Truss Beam • Dimensions of the X8 Rental Foot + Stacker • Dimensions of the X8 Flight Case for Rental Tiles • Dimensions of the foot beams R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 74: Dimensions Of The X8 Module

    A. Dimensions A.1 Dimensions of the X8 Module Dimensions X8 Module 43.3 379.6 86.3 Image A-1 Dimensions given in millimeters. R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 75: Dimensions Of The X8 Connection Box

    A. Dimensions A.2 Dimensions of the X8 Connection Box Dimensions X8 Connection Box 120.34 326.7 108.34 4 x Ø4.3 For plastic screws Image A-2 Dimensions given in millimeters. R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 76: Dimensions Of The X8 Rental Frame

    A. Dimensions A.3 Dimensions of the X8 Rental Frame Dimensions X8 Rental Frame 1140 Image A-3 Dimensions given in millimeters. R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 77: Dimensions Of The X8 Single Truss Beam

    A. Dimensions A.4 Dimensions of the X8 Single Truss Beam Dimensions X8 Single Truss Beam 1136 Image A-4 Dimensions given in millimeters. R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 78: Dimensions Of The X8 Dual Truss Beam

    A. Dimensions A.5 Dimensions of the X8 Dual Truss Beam Dimensions X8 Dual Truss Beam 2276 Image A-5 Dimensions given in millimeters. R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 79: Dimensions Of The X8 Rental Foot + Stacker

    A. Dimensions A.6 Dimensions of the X8 Rental Foot + Stacker Dimensions X8 Rental Foot + Stacker 1091 1140 Image A-6 Dimensions given in millimeters. R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 80: Dimensions Of The X8 Flight Case For Rental Tiles

    A. Dimensions A.7 Dimensions of the X8 Flight Case for Rental Tiles Dimensions X8 Rental Tile Flight Case 1265 1095 Image A-7 Dimensions given in millimeters. R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 81: Dimensions Of The Foot Beams

    A. Dimensions A.8 Dimensions of the foot beams Dimensions foot beams 1200 / 2400 / 4000 Image A-8 Dimensions given in millimeters. R5905160 X8 RENTAL DISPLAY 25/02/2013...
  • Page 82 A. Dimensions R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 83: Specifications

    B. Specifications B. SPECIFICATIONS Overview • Specifications of the X8 Rental Tile • Weight of individual parts of the X8 rental display R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 84: Specifications Of The X8 Rental Tile

    B. Specifications B.1 Specifications of the X8 Rental Tile Specifications Pixel pitch 8.6 mm Brightness 4,200 nits LED type 3-in-1 SMD Processing 16 bit/color 281 trillion Colors Refresh rate 3,200 Hz Hor. viewing angle 60/60° @50% brightness Vert. viewing angle +60/-60°...

  • Page 85: Weight Of Individual Parts Of The X8 Rental Display

    B. Specifications B.2 Weight of individual parts of the X8 rental display Weight of individual parts X8 Connection Box 6.9kg X8-8 module 2.0kg Total weight X8 tile cabling (module cabling + box cabling) 4.7kg 10.5kg X8 rental frame (without X8 Connection Box, modules and cables)
  • Page 86 B. Specifications R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 87: Order Info

    C. Order info C. ORDER INFO Overview • Spare part order info R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 88: Spare Part Order Info

    Order info: Order info Description R9004491F3 X8 Rental Tiles (3) in X8 Tile Flight Case (Three complete rental tiles in X8 Tile Flight Case) R9004491B1 X8 Rental Tile (One complete rental tile in cardboard package) R9801010B9 X8 Module (Nine pieces in box)

  • Page 89: Product Green Compliance

    About this chapter This chapter gives more information about Product Green Compliance. Product Green Compliance refers to the compliance of the X8 rental tile with environmental regulations and standards (such as EU RoHS, China RoHS, REACH, WEEE, ErP etc.). Overview •...

  • Page 90: Environmental Information

    For more information about recycling of this product, please contact your local city office or your municipal waste disposal service. For details, please visit the Barco website at: http://www.barco.com/en/AboutBarco/weee...

  • Page 91: Rohs Compliance

    Pollution Control Labeling Standard” of Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “Standard of Electronic Information Products Environmental Friendly Use Period” of Chinese Mainland.
  • Page 92 D. Product Green Compliance Turkey RoHS compliance Türkiye Cumhuriyeti: EEE Yönetmeliğine Uygundur. [Republic of Turkey: In conformity with the EEE Regulation] R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 93: Production Address

    D. Product Green Compliance D.3 Production address Factories Barco NV Noordlaan 5, B-8520 Kuurne (BELGIUM) R5905160 X8 RENTAL DISPLAY 25/02/2013...
  • Page 94 D. Product Green Compliance R5905160 X8 RENTAL DISPLAY 25/02/2013...

  • Page 95: Index

    Rental foot Dimensions Rental tile 45, 49 Software Rental tile on foot System requirements Stacker system Spare part order info Interconnection Specifications 79–80 X8 Connection Box X8 Modules Stacker system Introduction Install System overview Maintenance R5905160 X8 RENTAL DISPLAY 25/02/2013...
  • Page 96 Index Diagnostic Dimensions Truss Replace X8 Module X8 parts Weight Updates X8 Rental Frame X8rental tile Components X8 Connection Box 21, 63–64, 71 R5905160 X8 RENTAL DISPLAY 25/02/2013...
