- Page 1 X-series Safety manual For fixed indoor installation R5906876/00 24/07/2017...
- Page 2 Barco Visual (Beijing) Electronics Co., Ltd 地址：北京市 昌平区 中关村科技园 昌平园 昌盛路 16号 Phone: +86 10 8010 1166 Fax: +86 10 8970 2793 Support: www.barco.com/en/support Visit us at the web: www.barco.com Registered address: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium Phone: +32 56.23.32.11...
-
Page 3: Safety Guidelines
“warnings” and “cautions” are given depending on the installation procedure. Read and follow these “warnings” and “cautions” as well. Clarification of the term “X-series” used in this document When referring in this document to the term “X-series” means that the content is applicable for following Barco products: • X 1.2 •... -
Page 4: Notice On Safety
Structural & mounting components should be kept dry, clean, lubricated (only if recommended), coated properly, and otherwise maintained in a manner consistent with part design. Barco products must be used in a manner consistent with their design and inspected on a routine basis for security, wear, deformation, corrosion and any other circumstances that may affect the load handling capability of the part. -
Page 5: Important Warnings
To protect against risk of fire caused by overloading of power cables, the number of tiles connected in parallel is limited. See table below. Tile Power source Maximum number of tiles per power source cable X 1.2 110-180Vac 10 tiles 180-240Vac 14 tiles X 1.5... -
Page 6: Proper Usage
1. Safety X 2.5 110-180Vac 10 tiles 180-240Vac 14 tiles 110-180Vac 10 tiles 180-240Vac 14 tiles The power limits of the used power connectors needs to be followed. A C13/C14 connector is limited to 10A. An Amphenol connector is limited to 16A. ESD and LED’s: LED components used in X-series tiles are ESD (Electro-Static Discharge) sensitive. - Page 7 • Only Barco cables specified to be used with the X-series display are to be used to connect components in the X-series wall. Further, care must be taken to connect signal only according to the installation manual.
- Page 8 1. Safety R5906876 X-SERIES 24/07/2017...
-
Page 9: Environmental Information
(Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”. -
Page 10: Production Address
Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of environment-friendly use period of electronic information products” of Chinese Mainland.
