NetModule NB2500 User Manual page 66

Dial-in connection failure
Dynamic DNS registration
Dynamic DNS failure to reach server
Login to the Web Manager
Failed to Login to the Web Manager
Restart after power up
Restart due to a software exception
Restart due to Web Manager
Startup completed
Arriving UDP Message
Test Event
GPS reception on
GPS reception off
Digital Input 1 on
Digital Input 1 off
Digital Input 2 on
Digital Input 2 off
Digital Output 1 on
Digital Output 1 off
Digital Output 2 on
Digital Output 2 off
The following event variables will be replaced within event texts as follows:
Event Variables
%PPP_IP%
%PPP_ERR%
%VPN_IP%
%VPN_TYPE%
%DYNDNS_IP%
%DIN_USER%
%DIN_IP%
%LOGIN_USER%
%DIO_SOURCE%
%UDP_MESSAGE%
%RESTART_REASON%
%DST_IN1%
%DST_IN2%
%DST_OUT1%
%DST_OUT2%
User Manual NetBox Wireless Routers
26 October 2011
Dial-in failure to connect.
DYNDNS update with %DYNDNS_IP% address.
DynDNS failure to reach server.
Log-in to the Configuration GUI, by the user: %LOGIN_USER%.
Failed attempt to log-in to the Configuration GUI, by the user: %LOG-
IN_USER%.
Restart after power up.
Restart due to a software exception.
Restart due to Web Manager.
Startup completed
%UDP_MESSAGE%
This is a test.
GPS position is available.
GPS position is not available.
Input change: IN1 is On.
Input change: IN1 is Off.
Input change: IN2 is On.
Input change: IN2 is Off.
Output change: OUT1 is On, changed from %DIO_SOURCE%.
Output change: OUT1 is Off, changed from %DIO_SOURCE%.
Output change: OUT2 is On, changed from %DIO_SOURCE%.
Output change: OUT2 is Off, changed from %DIO_SOURCE%.
Description
The current IP address on the mobile interface (ppp0)
Error message in case of mobile connection failure
The current address of the OpenVPN interface
IPsec or OpenVPN
The IP address which has been sent to the DNS server
User name which the dial-in connection has been authenticated
against
The IP address of the dial-in peer
Name of the user who tried to log on to the Web Manager
Source that triggered an output change
Text message that has been received by the message receiver
Reason why a restart happened
Status of digital input 1, possible values include [on, off]
Status of digital input 2, possible values include [on, off]
Status of digital output 1, possible values include [on, off]
Status of digital output 2, possible values include [on, off]
netbox_manual_e_v1.4.docx
65/111
