3
Installation
3.4
Set up
Electrical connections
MicroCal iTC
Connect the power cord to the IEC 320 inlet power receptacle (see Figure 3-6 below) on
the back of the cell. Connect the power plug only to a main power supply receptacle
with a 3-wire protective Earth ground and a Ground Fault Circuit Interrupter (GFCI).
Figure 3-6. MicroCal iTC
Part
1
2 & 6
3
Washing module
Connect the power cord from the power supply to the power receptacle (see Figure 3-7)
on the rear of the Washing module (see Figure 3-6, Power). Connect the power supply
34
cell
200
WARNING
To enhance safety always plug the instrument into a Ground Fault
Circuit Interrupter (GFCI) device.
view of back plate.
200
Description
Fan
USB connectors
Mains power switch
Part
Description
4
Power fuses
5
IEC 320 inlet power receptacle
7
µP activity indicator
MicroCal iTC
Operating Instructions 28-9639-77 AA
200
1
2
3
4
5
6
7
