Feature
Formats
2.5.2. A
UDIO
Feature
Encoder
Inputs
Audio pairs may be split across up to four video streams or used on just one stream. Pairs must be
used in even numbers (odd pairs are invalid).
2.5.3. IP V
Feature
Type
Protocol
FEC
Note that the UltraCoder can stream or receive an IP video stream to the above specification
converting to or from ASI. Both the IP In (the extraction of ASI from an IP Video stream) and IP Out
(encapsulation of ASI into Ethernet) are chargeable licensed options.
IP In can be used as an external source the encoder and multiplexed with the internal encoder to
form multiple services.
The IP Out function enables ASI to be transmitted over Ethernet networks. Two IP streams can be
generated going to two different IP locations.
The source of IP for these two streams can independently come from either the internal encoder(s),
after multiplexer, or the external ASI connector.
The UltraCoder could be used as a standalone external ASI to IP encapsulator at the same time as
streaming the output of the internal encoder(s), to another IP destination.
Issue : 3 (16/12/2015)
Ref : ULTC-ASUM-7001
Description
480i @ 29.97
576i @ 25
720p @ 50, 59.94 & 60
1080i @ 50, 59.94 & 60
1080p @ 23.98, 24, 25, 29.97, 30, 50, 59.94 & 60
2160p @ 23.98, 24, 25, 29.97, 30, 50, 59.94 & 60
Description
ISO 14496-3 2006 (HE-AAC) 8 pairs
Embedded
IDEO
Description
10/100/1000 Base-T Ethernet
IEEE802.3 Ethernet
Encapsulation for ASI – RTP (RFC2250), ARP, IPv4, IGMPv2/3,
TCP/UDP
Pro-MPEG Forum Code of Practice #3 release 2 (CoP3)/
SMPTE 2022-2007
1-7 TS (ASI) packets per IP packet (configurable) with L&D
