5.1.1.2.4.
This item allows for the injected ID to be entered when using BISS E encryption. This key is fourteen
characters long, and will only be displayed for editing when BISS E encryption has been selected.

5.2. Audio Setup

1..8
Encoder
Input
Standard
PID
Rate
5.2.1. 1..8
These menus allow for each of the eight audio pairs to be configured.
5.2.1.1.
This option defines to which of the video streams being encoded the audio pair should be allocated.
Note that audio pairs must be allocated to video streams in pairs themselves, so that pairs one and
two, pairs three and four, pairs five and six, and pairs seven and eight are allocated to the same
encoder, and when editing a pair the corresponding pair's encoder setting will automatically change
to the same value. Each of these pair of pairs may be allocated to the same encoder, or different
ones, for example:
Pair One and Two
Pair Three and Four
Pair Five and Six
Pair Seven and Eight
5.2.1.2.
This option provides the facility to select which SDI audio group is allocated to a pair, or to use test
tones.
As with the Encoder setting, the input selection must be allocated to the audio pairs in pairs, so that
pairs one and two, pairs three and four, pairs five and six, and pairs seven and eight are allocated to
the same input, and when editing a pair the corresponding pair's input setting will automatically
change to the same group.
Each SDI group is composed of four audio channels, with the first two channels being allocated to
the first pair, and the second two channels being allocated to the second pair.
5.2.1.3.
This option provides the ability to select which audio standard to use for encoding, or to disable the
audio pair.
Note that unlike the Encoder and Input configuration, this setting may be set independently for each
of the eight audio pairs.
Issue : 3 (16/12/2015)
Ref : ULTC-ASUM-7001
Injected ID
E
NCODER
: Video-1 Encoder
: Video-2 Encoder
: Video-1 Encoder
: Video-4 Encoder
I
NPUT
S
TANDARD
