2. Specifications

2.1. Physical

Feature
Dimensions
Weight
Power Connector
AC Supply
Temperature Range
Humidity
Data
Ethernet Control & IP Video
USB Ports
SFP
ASI connections

2.2. Inputs

Feature
4 x HD-SDI
ASI

2.3. Outputs

Feature
ASI
IP Video

2.4. Remote Control/Monitoring

Feature
USB
Remote Control
IP Address (factory default)
Subnet Mask (factory default)
MAC Address

2.5. Performance

2.5.1. H.265 V
Feature
4K UHD Main 10
4K UHD Main 4.2.2 10
HD Main 10
HD Main 4.2.2 10
SD Main
SD Main 4.2.2
Issue : 3 (16/12/2015)
Ref : ULTC-ASUM-7001
Description
1RU half-width chassis x 350mm deep
1.9kg approx. (4lbs)
3 pin IEC plug with dual fusing
90-264V AC 50/60Hz @ <100VA
0 to +50°C operating, -20°C to +70°C storage
90% max. non-condensing
15way D-Type female
RJ45
Type A
HD BNC 75Ω
BNC 75Ω
Description
Standard interface SFP modules supplied. Optical/HDMI on request.
75Ω to ISO/IEC 13818-2 188Bytes constant rate
Description
75Ω to ISO/IEC 13818-2 188Bytes constant rate
10/100/1000 Base-T Ethernet
Description
For software upgrades
10/100Mb/s Web Browser/SNMP
192.168.0.90
255.255.255.0
00.1D.65.nn.nn.nn (n will be unit specific)
F , R
IDEO ORMATS ESOLUTION
Description
8/10 bit 4.2.0 1.0 – 25.0Mb/s
8/10 bit 4.2.0/4.2.2 1.0 – 25.0Mb/s
8/10 bit 4.2.0 1.0 – 20.0Mb/s
8/10 bit 4.2.0/4.2.2 1.0 – 20.0Mb/s
4.2.0 0.5 – 6.0Mb/s
4.2.2 2.0 – 6.0Mb/s
UltraCoder Operators Manual
& B
ITRATES
Specifications
Page : 3
