Fuse Replacement - ADJ 3D VISION PLUS User Instructions

3D Vision Plus
Disconnect the unit from its power source. Remove the power cord from the unit. Once the cord has
been removed, you will find that the fuse holder is located next to the powerCON IN socket. Use a
philips-head screw driver to unscrew and remove the fuse holder. Remove the bad fuse and replace
with a new one.
3D Vision Plus
Listed below are a few common problems the user may encounter, with solutions.
Unit not responding to DMX:
1. Check that the DMX cables are connected properly and are wired correctly (pin 3 is "hot"; on
some other DMX devices pin 2 may be 'hot'). Also, check that all cables are connected to the right
connectors; it does matter which way the inputs and outputs are connected.
Unit does not respond to sound:
1. Quiet or high pitched sounds will not activate the unit.
2. Make sure that Sound Active mode is activated.
3D Vision Plus
Due to fog residue, smoke, and dust cleaning the internal and external optical lenses must be car-
ried out periodically to optimize light output.
1. Use normal glass cleaner and a soft cloth to wipe down the outside casing.
2. Clean the external optics with glass cleaner and a soft cloth every 20 days.
3. Always be sure to dry all parts completely before plugging the unit back in.
Cleaning frequency depends on the environment in which the fixture operates (i.e. smoke, fog resi-
due, dust, dew).
ADJ Products, LLC - www.adj.com - 3D Vision Plus User Manual Page 18

Fuse Replacement

Trouble Shooting
Cleaning
