3D Vision Plus
ADJ Products, LLC - www.adj.com - 3D Vision Plus User Manual Page 16
10M threaded mounting hole
(to attach pro clamp to lock on truss)
quick release panel lock
to connect adjoining panels
PL Quick Release: SKU# 3DV175
Quick Release panel lock is used to connect the
units to one another. See page 15.
Hanging Bracket: SKU# 3DV149
Mounting and Grouping
crosshole (to
hang on a stud or
hook)
Rigging bar attachment points
