3D Vision Plus

Operating Instructions

System Menu: When making adjustments press ENTER to confirm your setup then press and
hold the MENU button for at least 3 seconds. To exit without making any adjustments press
the MENU button. The display will lock after 30 seconds, press the MENU button for 3 sec-
onds to unlock.
Please refer to the system menu on page 10 for detailed layout.
DMX Address - With this function, you can adjust the desired DMX-address via the Control Board.
1. Press the MENU button so that "Addr" is displayed, and press ENTER.
2. Press the UP or DOWN buttons The current DMX address will now be displayed.
3. Use the UP or DOWN buttons to adjust the DMX address.
4. Press ENTER to confirm or press MENU button to return to the main menu.
DMX Channel Mode - With this function, you can see the how many DMX channels the fixture has.
1. Press the MENU button so that "NodE" is displayed, and press ENTER.
2. The current DMX channel mode will be displayed. The default DMX channel mode is 9 channel mode. Use
the UP or DOWN buttons to scroll to your desired DMX channel mode, and press ENTER to set it.
3. Press the MENU button to exit and return to the main menu with no changes.
This mode can be used as a precaution mode, that in case the DMX signal is lost, interrupted,
DMX State -
or power is lost, the operating mode chosen in this setup is the running mode the fixture will go into
when the DMX signal is lost. Note: Hold is the default setting.
1. Press the MENU button so that "Nodn" is displayed, then press ENTER.
2. Press the UP or DOWN buttons until "DMX State" is displayed, and press ENTER. Use the UP and DOWN
buttons to switch between the four modes; Blackout, Auto, Sound Active, or Hold. Press the ENTER button to
make your selection.
• blac - If the DMX signal is lost or interrupted, the unit will automatically go into stand by mode.
• Auto - If the DMX signal is lost or interrupted, the unit will automatically go into auto program mode.
• Soun - If the DMX signal is lost or interrupted, the unit will automatically go into sound active mode.
• Hold - If the DMX signal is lost the fixture will stay in the last DMX setting. If power is applied and this mode
is set, the unit will automatically go into the last DMX set up. This is the default setting.
3. Press the MENU button to return to the main menu.
Master-Slave Set Up - With this function, you can see the how many DMX channels the fixture has.
1. Press the MENU button so that "SLAu" is displayed, and press ENTER.
2. The current setting will be displayed. Use the UP or DOWN buttons to toggle between "Slave" (SLAu) or
"Master" (NASt), and press ENTER to select your setting.
3. Press the MENU button to exit and return to the main menu with no changes.
ADJ Products, LLC - www.adj.com - 3D Vision Plus User Manual Page 11
