Module Programming - Directed DB3 Installation Manual

Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Wait until the LED turns ON solid red.
1
Note: To skip the transponder programming and use convenience features only, press
the programming button 5 times. When the LED turns ON solid orange, proceed to
step 2.
2
Insert and turn the key to ON, OFF, then remove the key.
Insert and turn the key to ON once more. When the LED starts flashing orange slowly,
turn the ignition OFF, remove the module from the vehicle and reconnect it to your
3
computer. The web site will automatically recognize that you are moving onto the
second phase of the programming sequence.
4
Click on Submit Key2GO Request.
Once the configuration is completed, reconnect the module. The LED turns ON solid
5
green for 3 seconds, then turns OFF.
You have successfully completed the module programming sequence.
12
403.CHRYSLER6 2.04 2016 Dodge/Ram 1500
© 2018-01-30 Directed. All rights reserved.
