Problem Solving

» Check the DIP-switch configuration. It must be set in the same operational mode as the
corresponding link.
» Select the proper UTP/fiber optic cable to construct your network. The single-mode media
converter must use single-mode fiber optic cable. Please check that you are using the right
cable.

Optical Fiber Specifications

The following table shows the optical Fiber Specification
Module Name Wavelength (nm)
CWFE2SCM2 1310 nm
CWFE2SCS2 1310 nm
Module Name Avg. Power Loss Budget (dBm) Max. FDX Fiber Distance (Km)
CWFE2SCM2 10 dBm
CWFE2SCS2 15 dBm

Optical Specifications of Transceivers

1310 nm
Multimode
Single Mode
TECH SUPPORT: 1.888.678.9427
Transmitter (Output Center Wavelength): 1261~1360 nm
Receiver (Wavelength of Operation): 1100~1600 nm
Avg. Launch Power (dB)
-20 dB
-15 dB
3 km
30 km
CWFE2SC(M,S)2
Avg. Sensitivity (dB)
-30 dB
-30 dB
Fiber Size (um)
62.5/125
50/125
9/125
