LED Indicators

There are 6 diagnostic LEDs located on the Front panel of the media converter. They provide real-
time information of system and optional status. The indicator includes Power, UTP 100, LK/ACT,
FDX/COL, Fiber LK/ACT, FDX/COL. The following table provides description of the LED status and
their meanings.
LED Color
PWR Green
100 Green
LK/ACT (UTP) Green
Green
LK/ACT (Fiber) Green
Green
FDX/COL (UTP) Orange
Orange
FDX/COL (Fiber) Orange
Orange
TECH SUPPORT: 1.888.678.9427
Status Description
On Power On
On 100 Mbps UTP Speed
Off 10 Mbps UTP Speed
On The unit is linking with its link partner.
Blinking The unit is transmitting or receiving packets from UTP devices.
Off No device attached
On The unit is linking with its link partner.
Blinking The unit is transmitting or receiving packets from FX devices.
Off No device attached
On The UTP port is operating in full-duplex mode.
Blinking Collision of packets is occurring in the port.
Off Half-duplex mode or no device attached.
On The fiber port is operating in full-duplex mode.
Blinking Collision of packets is occurring in the port.
Off Half-duplex mode or no device attached.
CWFE2SC(M,S)2
QSG_CWFE2SC(M,S)2 Rev. 11.17.17 PAGE 5
