This manual serves the following
ComNet Model Numbers:
CNMCSFP/MV
CNMC2SFP/V
INSTALLATION AND OPERATION MANUAL
CNMC[2]SFP/[M]V Series
10/100/1000MBPS ETHERNET TO VDSL2 MEDIA CONVERTERS
The ComNet CNMC[2]SFP/[M]V series Ethernet to VDSL2 media converters accept a
10/100/1000 Mbps electrical input and convert this to a SFP-VDSL output and the
SFP-VDSL input back to the 10/100/1000 Mbps electrical output. "Auto-Negotiating"
is supported on the copper interface side. Connect SFP-VDSL devices using a twisted
2-wire cable. Refer to connection paragraph for details. The series consists of a small-
size single channel model, CNMCSFP/MV, and a ComFit standard size, dual channel
model, CNMC2SFP/V.
The CNMC2SFP/V media converters are designed specially for the VDSL-SFP, sold
separately.
Rev. 01/04/21
INS_CNMCSFP/V
06/06/12
PAGE 1
