INSTALLATION AND OPERATION MANUAL
CWFE2SC(M,S)2
Commercial Grade 10/100 Mbps Ethernet
2 Port Electrical-to-Optical Media Converter
The ComNet ValueLine CWFE2SC(M,S)2 Ethernet 2-port media converters are designed
to transmit and receive a single channel of 10/100 Mbps data over multimode or single
mode optical fiber. The electrical interface will Auto-Negotiate to a 10 Mbps, or 100 Mbps
Ethernet rate without any adjustments. The optical interface operates at a 100 Mbps
Ethernet rate. These media converters are commercial grade for light industrial use.
Rev. 11.17.17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comnet CWFE2SC2
Summary of Contents for Comnet CWFE2SC2
- Page 1 Commercial Grade 10/100 Mbps Ethernet 2 Port Electrical-to-Optical Media Converter The ComNet ValueLine CWFE2SC(M,S)2 Ethernet 2-port media converters are designed to transmit and receive a single channel of 10/100 Mbps data over multimode or single mode optical fiber. The electrical interface will Auto-Negotiate to a 10 Mbps, or 100 Mbps Ethernet rate without any adjustments.
-
Page 2: Table Of Contents
INSTRUCTION MANUAL CWFE2SC(M,S)2 Contents Introduction Features Hardware Description Front Panel Ports LED Indicators DIP-switch Rear Panel Cabling Connections Problem Solving Optical Fiber Specifications Optical Specifications of Transceivers Technical Specifications TECH SUPPORT: 1.888.678.9427 QSG_CWFE2SC(M,S)2 Rev. 11.17.17 PAGE 2... -
Page 3: Introduction
3 kilometers for multi-mode fiber or up to 30 kilometers for single-mode fiber. The ComNet CWFE2SC(M,S)2 gives you the option of choosing between the most popular fiber cabling connectors: SC/multi-mode fiber connector and SC single-mode fiber connectors. The CWFE2SC(M,S)2 module provides you with one fiber port for your fiber optic cable and one Ethernet RJ45 port (Auto MDI/MDIX) for your 100Base-TX copper cable connection. -
Page 4: Hardware Description
Unit dimension (L × W × H) is: 119 × 85 × 26 mm Front Panel The Front Panel of the ComNet CWFE2SC(M,S)2 consists of one RJ-45 Port (Auto MDI/MDIX), 6 LED Indicators (UTP 100, LK/ACT, FDX/COL, Fiber LK/ACT, FDX/COL and PWR) and one fiber 100Base-FX Port. -
Page 5: Led Indicators
INSTRUCTION MANUAL CWFE2SC(M,S)2 LED Indicators There are 6 diagnostic LEDs located on the Front panel of the media converter. They provide real- time information of system and optional status. The indicator includes Power, UTP 100, LK/ACT, FDX/COL, Fiber LK/ACT, FDX/COL. The following table provides description of the LED status and their meanings. -
Page 6: Dip-Switch
INSTRUCTION MANUAL CWFE2SC(M,S)2 DIP-switch The DIP-switch is used to configure operation mode for LLF (Link Lost Forwarding) and operation mode for UTP/Fiber port. The default value of DIP switch is OFF. SW No Status Description UTP 100 Mbps Full Duplex Mode UTP Auto-Negotiate Fiber in Half Duplex Fiber in Full Duplex... -
Page 7: Rear Panel
INSTRUCTION MANUAL CWFE2SC(M,S)2 Rear Panel The rear panel contains a power socket, which accepts 5-12 VDC @ 2.7 W. Connect the included Power Supply to the rear panel DC IN jack. Plug the AC input of the Power Supply to a commercial power source. DC IN Fast Fiber Converter Module - Rear Panel Cabling... -
Page 8: Problem Solving
INSTRUCTION MANUAL CWFE2SC(M,S)2 Problem Solving » Check the DIP-switch configuration. It must be set in the same operational mode as the corresponding link. » Select the proper UTP/fiber optic cable to construct your network. The single-mode media converter must use single-mode fiber optic cable. Please check that you are using the right cable. -
Page 9: Technical Specifications
INSTRUCTION MANUAL CWFE2SC(M,S)2 Technical Specifications ComNet CWFE2SC(M,S)2 technical specifications are as follows: Standard IEEE802.3 10BASE-T IEEE802.3u 100BASE-TX/100BASE-FX IEEE802.3x Flow Control and Back pressure Connector Fiber: Duplex SC RJ45 Socket: CAT-3/5 (10/100Mbps) Twisted Pair cable Auto MDI/MDI-X and Auto-Negotiation Function Support... - Page 10 8 TURNBERRY PARK ROAD | GILDERSOME | MORLEY | LEEDS, UK LS27 7LE T: +44 (0)113 307 6400 | F: +44 (0)113 253 7462 | INFO-EUROPE@COMNET.NET © 2017 Communications Networks Corporation. All Rights Reserved. “ComNet” and the “ComNet Logo” are registered trademarks of Communication Networks, LLC.
