Creating Bridge WAN Connection

To create a connection of the Bridge type, click the Add button on the Connections Setup /
WAN page in the Connections List section. On the opened page, go to the All Settings tab.
Then select the relevant value from the Connection Type drop-down list and specify the needed
values.
Figure 71. The page for creating a new Bridge connection. Selecting a connection type.
Parameter
Interface
Enable connection
Connection name
A physical interface to which the new connection will be assigned.
In order to create a VDSL WAN connection, select the PTM value.
In order to create an ADSL WAN connection, select the value
corresponding to the existing interface or the Add new ATM PVC
value for creating a new interface at the physical layer.
Move the switch to the right to enable the connection.
Move the switch to the left to disable the connection.
A name for the connection for easier identification.
Page 90 of 168
Configuring via Web-based Interface
Description
