DSL-224 Wireless VDSL2 Router with ASDL2+ Support
User Manual
LED
Solid green
WLAN
Blinking green
No light
Solid green
LAN 1-4
Blinking green
No light
Blinking green
WPS
No light

Side Panel

Name
RESET
Mode
A client has connected to the WLAN.
The router's WLAN is on.
The router's WLAN is off.
A device is connected to the port of the router.
The relevant LAN port is active (upstream or downstream traffic).
The cable is not connected to the relevant port.
Attempting to add a wireless device via the WPS function.
The WPS function is not in use.
Figure 2. Side panel view.
A button to restore the factory default settings.
To restore the factory defaults, push the button (with the device turned on),
hold it for 10 seconds, and then release the button.
