VLT® Decentral FCD
Output frequency lower than f
HIGH
(below frequency high)
Output current higher than I
LOW
(above current low)
Output current lower than I
HIGH
(below current high)
Feedback higher than FB par. 227
LOW
(above feedback low)
Feedback lower than FB par. 228
HIGH
(under feedback high)
Relay 123 (RELAY 123)
Reversing (REVERSE)
Thermal warning (THERMAL WARNING)
Local operation (LOCAL MODE)
Out of frequency range par. 225/226
(out of freq range)
Out of current range
(out of current range)
Out of feedback range
(out of fdbk. range)
Mechanical brake control
(Mech. brake control)
Control word bit 11
(CTRL W. BIT 11)
Function:
The relay output can be used for giving the present status or warning.
The output is activated (1–2 make) when a given condition is fulfilled.
Description of choice:
No function . Is selected if the frequency converter is not to react to sig-
nals.
Unit ready
, there is a supply voltage on the control card of the frequency
converter, and the frequency converter is ready for operation.
Enable, no warning
, the frequency converter is ready for operation, but
no start command has been given. No warning.
Running , a start command has been given.
Running in reference, no warning
speed according to reference.
Running, no warning
, a start command has been given. No warning.
Ready - mains voltage within range
, the frequency converter is ready for
use; the control card is receiving a supply voltage; and there are no active
control signals on the inputs. The mains voltage lies within the voltage
limits.
Alarm or warning , the output is activated by an alarm or warning.
Current limit
, the output current is higher than the value programmed in
parameter 221 Current limit I .
LIM
Alarm , The output is activated by an alarm.
Output frequency higher than f
, the output frequency is higher than
LOW
the value set in parameter 225 Warning: Low frequency, f
Output frequency lower than f ,
HIGH
Warning: High frequency, f
the value set in parameter 226
Output current higher than I
, the output current is higher than the
LOW
value set in parameter 223 Warning: Low current, I
Output current lower than I , the output current is lower than the
HIGH
Warning: High current, I
value set in parameter 224
Feedback higher than FB
, the feedback value is higher than the value
LOW
Warning: Low feedback, FB
set in parameter 227
par. 226
[12]
par. 223
[13]
par. 224
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[22]
[23]
[24]
[25]
[26]
.
LOW
the output frequency is lower than
.
HIGH
.
LOW
.
HIGH
.
LOW
MG.04.B8.02 - VLT is a registered Danfoss trademark
Feedback lower than FB
, the feedback value is lower than the value
HIGH
Warning: High current, I
set in parameter 228
Relay 123
is only used in connection with Profidrive.
Reversing
, The relay output is activated when the direction of motor ro-
tation is anti-clockwise. When the direction of motor rotation is clockwise,
the value is 0 V DC.
Thermal warning , above the temperature limit in either the motor or the
frequency converter, or from a thermistor connected to a digital input.
Local operation, the output is active when in parameter 002
operation, Local operation
[1] has been selected.
Out of the frequency range,
the output frequency is out of the program-
med frequency range in parameters 225 and 226.
Out of the current range,
the motor current is out of the programmed
range in parameters 223 and 224.
Out of the feedback range, the feedback signal is out of the programmed
range in parameters 227 and 228.
Mechanical brake control,
enables you to control an external mechanical
brake (see section about control of mechanical brake in the Design
Guide).
Control word bit 11, bit 11of the control word, the relay output will be
set/reset according to bit 11.
327 Pulse Max. 33
Value:
150 - 110000 Hz
Function:
This parameter is used for setting the signal value that corresponds to
the maximum value set in parameter 205
to the maximum feedback value set in parameter 415
back, FB .
MAX
Description of choice:
Set the required pulse reference or pulse feedback to be connected to
terminal 33.
328 Pulse Max. 29
Value:
1000 - 110000 Hz
Function:
This parameter is used for setting the signal value that corresponds to
the maximum value set in parameter 205
to the maximum feedback value set in parameter 415
back, FB
.
MAX
Description of choice:
Set the required pulse reference or pulse feedback to be connected to
terminal 29.
341 Digital output terminal 46
Value:
No function (NO OPERATION)
Value [0] - [20] see parameter 323
Pulse reference (PULSE REFERENCE)
Value [22] - [25] see parameter 323
Pulse feedback (PULSE FEEDBACK)
Output frequency (PULSE OUTPUTFREQ)
Pulse current (PULSE CURRENT)
Pulse power (PULSE POWER)
3 Programming
.
HIGH
Local/remote
5000 Hz
Maximum reference, Ref
or
MAX
Maximum feed-
5000 Hz
Maximum reference, Ref
or
MAX
Maximum feed-
[0]
[21]
[26]
[27]
[28]
[29]
59
3
