TROUBLESHOOTING AND MAINTENANCE
AccuPyc 1330
MAINTENANCE
GREASING THE CHAMBER CAP O·RING
The cell chamber cap contains an O-ring that requires routine maintenance because it is so often
exposed. The chamber cap O-ring should be greased at the beginning of each period of use.
1.
Remove the chamber cap by turoing it counterclockwise then lifting off.
2.
Wipe off the old grease using lint-free tissue.
3.
Using your fingertips. apply a !hin layer of Dow Coroing high vacuum grease (or equiva-
lent) to the greasing disko
4.
Insert the greasing disk into the chamber cap and turn slightly to apply a very light coating
of grease to the O-ring.
Figure
5-1.
Greastng Chamber Cap O-Rtng
5-12
15 Dec 89
•
