Entering the Fluid
Parameters
Initial Setup
To program your fluid parameters, scroll to the Fluid tab on the
Program Menu (see Figure 2-5 below) and press
Transducer
Tracking Windows?
Fluid
Sound Speed
Speed Min
Speed Max
77
Temp
Figure 2-5: The Fluid Option Window
1. Indicate if you want to use "Tracking Windows" by scrolling to
the "No" or "Yes" button. Press
Note: The "Tracking Windows" feature is used to detect the
transducer signal when you are unsure of your fluid sound
speed (the default setting is "No").
2. At the "Fluid" prompt, press
Scroll to your fluid type (see the list of available fluids in Table
3-2 on the next page), or if your fluid is not listed, select "Other."
Press to confirm your selection
[ENTER]
Note: The list of available fluid types will vary, depending on the
choices you made for the Tracking Windows and Energy
options.
3. To return to Operate Mode, press
or press (Cancel) to cancel your entries.
[F2]
Transducer/Pipe
Fluid
Fluid
Pipe Lining
No
Water (2C)
1496
m/s
1350 m/s
m/s
1650
%
Glycol 10
°F
Cancel
to confirm your selection.
[ENTER]
to open the drop-down list.
[ENTER]
(OK) to confirm your entries
[F3]
