GE Transport PT878 Abridged Manual page 82

August 2008
The New Option (cont.)
5-6
1. Use the [
] and [ ] arrow keys to scroll until the General tab is
highlighted.
2. Press the [ ] key to select the Measurements tab. Press
and the Measurements window (see Figure 5-6 below) opens.
General
Measurements
NO UNIT
NO UNIT
NO UNIT
NO UNIT
NO UNIT
NO UNIT
Figure 5-6: The Measurements Window
3. Scroll to the first table cell and press
Measurement window opens (see Figure 5-7 below).
Select Measurement
Diagnostics
Velocity
Volume
Fwd Totalizer
Rev Totalizer
Energy
No Unit
Figure 5-7: The Select Measurement Window
Ns
NO UNIT
NO UNIT
NO UNIT
NO UNIT
NO UNIT
NO UNIT
Cancel
Activate
. The Select
[ENTER]
Meters/sec
Feet/sec
Cancel OK
[ENTER]
Data Logging
